红外热波序列图像的图像分割与三维显示

基金项目:

国家863计划项目“红外热波无损检测技术在复合材料研究中的应用”的资助(2003AA333090)

详细信息

Segmentation and 3D Display of Infrared Thermal Image

摘要: 研究了针对红外热波序列图像的图像分割和三维显示方法。红外热波无损检测只能得到被测工件表面温度变化的时间序列图像，无法直观到检测缺陷，利用三维显示技术可以产生深度三维立体图，方便技术人员更直观、精确地进行无损检测。三维显示效果的好坏直接取决于图像分割的效果。为此提出了基于局部极小值的区域生长分割算法，成功地提取出红外热波图像中缺陷成分的目标图像，并进行了三维显示，取得了较好的效果。
- 红外热波 /
- 图像分割 /
- 三维显示
Abstract: The segmentation and 3D display method of infrared thermal image were studied. Infrared thermal detecting can not be implemented well because it can only get thermal sequence images, so it is needed to produce three-dimensional images of depth using 3D display technology. 3D display has a direct effect on image segmentation results, so a new algorithm of the region growing segmentation based on the minimization. It successfully extracted the target image of the defect elements and achieved a better result in the 3D display.
- Infrared thermal wave /
- Image segmentation /
- 3D reconstruction

[1]	Stephane Bonnet, Anne Koenic. Dynamic X-ray computed tomography[J]. Proceeding of the IEEE,2003,91(10):1574-1588.
[2]	Akira Hirakimoto. Microfocus X-ray computed tomography and its industrial applications[J]. Analytical Sciences,2001,17(Supplement):1123-1125.
[3]	金万平,张存林.材料检测和表征的新技术——热波检测及其应用[J].新材料产业,2004,(9):52-55.
[4]	覃仁超.一种工业CT图像的分割算法[J].微计算机信息,2006,22(5):221-223.
[5]	崔屹.图像处理与分析——数学形态学方法与应用[M].北京：科学出版社,2000.
[6]	郭景峰.数学形态学中结构元素的分析研究[J].计算机科学,2002,29(7):113-115.
