复合材料喷水超声检测工艺

基金项目:

国家自然科学基金资助项目(60871101)

详细信息

Research on Water-Squirting Ultrasonic Testing Parameters for Composite Materials

摘要: 为研究航空复合材料喷水超声穿透法检测工艺, 研制了专用的喷嘴和探头, 建立了一套复合材料超声喷水检测试验系统。基于此系统, 对喷水速度、喷水距离和喷水角度等参数对超声检测的影响规律进行了试验研究。研究结果表明, 这些工艺参数对检测结果都有较大影响, 提出了参数的合理选择范围。该研究对复合材料喷水超声自动检测系统的设计和检测工艺参数的优化具有重要的意义。
- 复合材料 /
- 喷水 /
- 超声波检测 /
- 检测工艺
Abstract: In order to study ultrasonic through-transmission testing technique based on water-squirting coupling for aerospace composites, a water-squirting ultrasonic testing system is developed, with specific nozzle and two probes being designed and applied in the system. Based on this system, the water-squirting parameters, such as squirting speed, squirting distance and squirting angel are experimentally studied, and the affecting regulations are obtained. Experiments show that technical parameters greatly affect testing results, and their reasonable ranges of choice are given. The conclusions are of great significance for design of automatic water-squirting ultrasonic testing system and optimization of the testing technical parameters.
- Composite materials /
- Water-squirting /
- Ultrasonic testing /
- Testing parameters

[1]	陈先有, 曹金华, 黄俊波.航空用复合材料结构件无损检测技术分析[J].国防技术基础, 2007, 7(8): 11-14.
[2]	刘怀喜, 张恒, 马润香.复合材料无损检测方法[J].无损检测, 2003, 25(12): 631-634.
[3]	Karl V Steiner, Rushad F Eduljee, Xiaogang Huang, et al. Ultrasonic NDE techniques for the evaluation of matrix cracking in composite laminates[J]. Composites Science and Technology, 1995, 53(2): 193-198.
[4]	Balasubramaniam K, Sean C Whitney. Ultrasonic through-transmission characterization of thick fibre-reinforced composites[J]. NDT&E International, 1996, 29(4): 225-236.
[5]	李光浩.现代民用飞机复合材料的无损检测[J].无损检测, 2001, 23(5): 213-214.
