Comparison of Surface Wave Antenna and Piezoelectric Ceramic Transducer in Receiving Ultrasonic Guided Wave Signal
-
摘要: 在一定条件下，超声导波检测试验中的压电陶瓷片可以作为一种表面波天线生成电磁波。将表面波天线技术应用于结构的超声导波检测，并将表面波天线接收信号与压电陶瓷片接收信号进行对比，两者完全吻合，表明表面波天线可以有效接收到超声导波检测信号。同时，对表面波天线位置对接收信号的影响进行了试验研究，发现天线处于不同位置时，接收信号在时间轴上完全吻合，且当其与试件距离不变时，接收信号无明显变化，符合表面波的传播特性。Abstract: Under certain conditions, a piezoelectric ceramic used in ultrasonic guided waves test can generate electromagnetic waves as a surface wave antenna. The antenna technology was applied to structural experiment of ultrasonic guided wave. Compared the signals received by the antenna with those by a piezoelectric ceramic it was obvious that they agreed well with each other, which meaned a surface wave antenna could effectively receive detection signals of ultrasonic guided wave. Meanwhile, the effect with the antenna position was researched, it found that, when the antenna was in a different location, the recieved signals were consistent at time axis, moreover, when it keeped destance to the sample, the signals were not significantly changed and the detection signals accord with the transmission character of surface waves.
-
Keywords:
- Guided waves /
- Electromagnetic waves /
- Antenna /
- Surface waves
-
-
[1] 吴 斌,李隆涛,王秀彦,等.基于超声导波技术对钢杆表面缺陷的无损检测研究[J].工程力学,2003,20(5):149-154. [2] 刘伟娜,刘培涛,肖建康.TM0模式下PBG接地板与开槽接地板微带贴片天线的性能研究[J].兰州理工大学学报,2006,32(2):105-107. [3] 郑秋容,袁乃昌,林宝勤.紧凑型电磁带隙结构短路销钉微带天线[J].国防科技大学学报,2006,28(1):33. [4] John D. Kraus, Ronald J. Marhefka,著.天线(下)[M].章文勋,译.北京:电子工业出版社,2005. [5] 卢万铮.天线理论与技术[M].西安:西安电子科技大学出版社,2004. [6] 吴 斌, 孙雅欣,何存富,等.全长黏结型锚杆高频超声导波检测应用研究[J].岩石力学与工程学报,2007,26(2):397-404.
