静载荷下硅钢片的磁畴结构变化

基金项目:

国家自然科学基金资助项目(51065022)

教育部NDT重点实验室开放基金资助项目(ZD200729012)

详细信息

Magnetic Domains Structure Chang of Silicon Steel Sheet Under Static Loads

摘要: 利用Bitter粉纹法观察了未经磁化、受力程度不同的无取向硅钢片试件的磁畴结构，对比分析了应力对磁畴及磁场值ΔB的影响。结果表明：无取向硅钢试件在未受力或应力集中较小时，晶粒内磁畴以180°剑状畴为主，同一晶粒内畴壁相互平行；随着应力集中程度增加，畴壁长度和间距发生改变，出现了迷宫畴，并且随着应力集中程度越大，迷宫畴的数量越多，表面磁场值ΔB越大。试验为探讨磁记忆检测的微观机理提供了依据。
- 磁畴结构 /
- Bitter粉纹法 /
- 迷宫畴 /
- 畴壁
Abstract: The magnetic domains of silicon steel sheet, which was not magnetized and was loaded on different intensity or direction, were observed with the Bitter method. The effect of stresses on magnetic domains and the magnetic signals ΔB was then analyzed. The results show that there mainly exist 180° gladiate domains for the silicon steel sheet with low load or no load, with their walls being small in the same crystalline grain. Then, with the load enhancing, the domain walls length and space are changed and the mazy domains appear. The number of the mazy domains and the magnetic signals of ΔB increase with the load increasing.
- Magnetic domain structure /
- Bitter method /
- Mazy domain /
- Domain wall

[1]	任吉林，林俊明.金属磁记忆检测技术［M］.北京：中国电力出版社,2000:44-78.
[2]	邸新杰，李午申.金属磁记忆在焊接缺陷检测领域的研究现状及发展［J］.焊接技术,2009,38(2):2-4.
[3]	耿荣生.磁记忆检测技术在飞机结构件早期损伤监测的应用前景［J］.无损检测,2002,24(3):118-122.
[4]	Withers P J, Turski M, Edwards L, et al. Recent advances in residual stress measurement［J］. International Journal of Pressure Vessels and Piping,2008,85(3):118-127.
[5]	张丽慧，安颖.磁畴结构是来源于能量最小原理的定性分析［J］.河北理工学院学报,2005,27(3):105-121.
[6]	杨全民.铁磁性的物理本质［J］.连云港师范高等专科学校学报,2004,6(2):89-91.
[7]	Shindo Y, Komatsu T. Magnetic stress intensity factor for an edge crack in a soft ferromagnetic elastic half-plane under tension［J］. Acta Mechanica,2006:182-184.
[8]	任吉林，白鹭，范振中，等.航空铁磁材料磁记忆检测新方法［J］.航空学报,2009,11(30):2224-2228.
[9]	钟文定.铁磁学(中册)［M ］.北京：科学出版社,2000:37-48.
