兰姆波在薄钢板无损检测中的应用研究

基金项目:

湖北省自然科学基金(2004ABA019)；湖北省教育厅基金项目(2004D009)；宁波市自然科学基金(2006A610025)

详细信息

Experimental Study for Nondestructive Testing of Steel Sheet by Lamb Waves

摘要: 通过在钢板上钻制直径不等的孔来模拟钢板中的孔洞类缺陷，采用线切割加工出不同深度的狭缝来模拟钢板中的分层缺陷。采用一发一收法，分别在两种厚度的钢板上激励出兰姆波进行检测，通过对比分析检测到的缺陷前后板中兰姆波信号，采用时频分析方法识别出板中激发的兰姆波模式以及模态转换现象，初步确定特定缺陷形态对兰姆波在板中传播的影响。
- 无损检测 /
- 兰姆波 /
- 时频分析
Abstract: The holes with different diameter were drilled in the steel sheet to simulate the hole-class defects, and slots with different depth were cut by WEDM in the steel sheet to simulate the lamination defects. The two types of plates were detected by pitch-catch technique with Lamb waves respectively. Signals which were detected in the defect-free plate and plate with defect were compared. Time-frequency analysis was employed to recognize the Lamb wave modes and mode conversion, and some effect of the given defects on Lamb waves in the steel sheet is determined primarily.
- Nondestructive testing /
- Lamb waves /
- Time-frequency analysis

[1]	蒋福棠，何双起，沈建中.兰姆波探伤中一些问题的探讨[J].材料工程,1996,41(10):29-31.
[2]	刘镇清.无损检测中的超声兰姆波［J］.无损检测,1999,21(9):409-423.
[3]	Krautkramer J.超声检测技术［M］.李靖，等，译.广州：广东科技出版社,1984:277.
[4]	Cohen L. Time-frequency distributions: a review［J］. Proceedings of the IEEE,1989,77(7):941-981.
[5]	Proser W H, Seale Michael D. Time-frequency analysis of the dispersion of Lamb modes［J］. J Acoust Soc Am,1999,105(5):2669-2676.
[6]	[美]阿肯巴赫.弹性固体中波的传播［M］.洪锦如，译.上海：同济大学出版社,1992.
