单通道TOFD检测仪校准方法

详细信息

Calibration Methods of Single Channel TOFD Testing Instrument

摘要: 介绍了TOFD仪器的工作原理和单通道TOFD检测仪的两种深度校准方法：直通波校准、直通波和底面反射波共同校准。分别就两种校准方法进行了推导，提出了各种不同校准方法的优缺点及每种校准方法的应用范围。
- 超声衍射时差法 /
- 直通波 /
- 校准
Abstract: This paper introduced the working principle of the TOFD equipment and two depth calibration methods of single-channel TOFD equipment, i.e. lateral wave calibration, lateral wave and back wall echo calibration. Derivation of the two calibration methods, the advantages and disadvantages of various calibration methods and the scope of application of each calibration method were discussed.
- Time of flight diffraction /
- Lateral wave /
- Calibration
