Ultrasonic Liquid Level Indicator
-
摘要: 介绍利用单片机W77E58作为主控元件的超声波液位测量原理，给出设计方法和系统框图。该液位测量仪具有温度补偿，用标准反射杆作基准进行校正，可提高测量精度，且价格低廉，可靠性高。Abstract: The theory of ultrasonic liquid level testing was introduced. The design and the frame of the system with temperature compensation and the standard reflect as the basis for calibration were detailed, in which MCU W77E58 was used as the main control component. The measuring results showed that the system was low in price and high in reliability.
-
Keywords:
- Ultrasonic testing /
- Liquid level indicator /
- Temperature compensation
-
-
[1] 克劳特克洛德J，等著，李 靖，等译.超声检测技术.［M］.广州：广东科技出版社,1984.262-281. [2] 何立民. MCS-51系列单片机应用系统设计［M］.北京：北京航空航天大学出版社,1993.50-400. [3] 北京市技术交流站.超声波探伤原理及其应用\[M\].北京：机械工业出版社,1982.50-180.
