A shearography nondestructive testing instrument for composite based on Wollaston prism
-
摘要:
激光错位散斑干涉技术具有全场非接触、高精度和高灵敏度等优点,被广泛应用于复合材料的无损检测领域。针对实际工程应用中的复合材料缺陷检测,提出了一种结构紧凑、抗干扰能力强的基于沃拉斯顿棱镜的错位散斑干涉无损检测仪,实现了对缺陷的实时动态检测。使用该检测仪对不同类型复合材料中的缺陷进行检测,检出率可达97%,可检测的最小缺陷尺寸为ϕ2 mm。
Abstract:Shearography technique has the advantages of full-field noncontact, high precision and high sensitivity, and is widely used in the field of nondestructive detection of composites. For the practical engineering application of composite defect detection, a shearography nondestructive instrument based on a Wollaston prism with compact structure and strong anti-interference ability was proposed, so as to realize real-time dynamic defect detection. The system was used to teste the different types of composite materials. It achieved a detection rate of 97% and can detect defects as small as 2 mm.
-
Keywords:
- shearography /
- composite /
- Wollaston prism /
- dynamic measurement
-
-
Table 1 碳纤维层压复合板缺陷的检出率
缺陷形状 缺陷大小 缺陷深度 检出率 圆形 Φ 3 mm ≥1 mm 91% <1 mm 93% Φ 6 mm和Φ 10 mm ≥1 mm 95% <1 mm 97% 矩形 2 mm×10 mm 0.5 mm 92% 12 mm×6 mm 10 mm×2 mm 94% 4 mm×4 mm
下载: 导出CSV
-
[1] GHOBADI A ．Common type of damages in composites and their inspections[J]．World Journal of Mechanics,2017, 7(2):24-33. [2] 张旭刚,张素香,程旭,等 ．层压结构复合材料的激光剪切散斑检测[J]．无损检测,2014, 36(7):56-59. [3] 刘元林,赵国金,高帅帅,等 ．碳纤维复合材料缺陷无损检测方法研究[J]．煤矿机械,2017, 38(12):64-66. [4] 刘菲菲,刘松平,傅天航,等 ．复合材料结构中R区的超声波反射行为及其检测应用[J]．机械工程学报,2017, 53(12):35-43. [5] 程文,张宏菊 ．激光剪切散斑检测技术在飞机复合材料检测中的应用[J]. 青岛大学学报：工程技术版, 2012, 27(4):80-83, 94. [6] 史建军,李得天 ．碳纤维复合材料气瓶的X射线实时成像技术[J]. 宇航材料工艺, 2009, 39(6):65-66. [7] 曹峰,周庆祥,邱国云,等 ．碳纤维复合材料平板分层缺陷的MIT检测[J]．仪表技术与传感器,2019(7):96-100, 105. [8] FRANCIS D ,TATAM R P ,GROVES R M ．Shearography technology and applications：a review[J]．Measurement Science and Technology,2010, 21(10):102001. [9] ZHANG F ,XIAO Z T ,GENG L ,et al ．Correlation fringe pattern of ESPI generated method based on the orientation partial differential equation[J]．Optics Communications,2014, 310:85-89. [10] FENG Z A ,GAO Z ,ZHANG X Q ,et al ．Research on key factors in the digital shearing speckle pattern interferometry[C]//Proc SPIE 9621,2015,9621：62-67． [11] YAN P Z ,LIU X W ,WU S L ,et al ．Pixelated carrier phase-shifting shearography using spatiotemporal low-pass filtering algorithm[J]．Sensors,2019, 19(23):5185. [12] 李慧娟, 张京焘,黄振华 ．激光剪切散斑方法对脱黏缺陷的定量测量[J]. 宇航材料工艺, 2011, 41(5):85-88. [13] 徐子鹏,韩旭,李丽娟,等 ．碳纤维复合材料冲击损伤的激光错位散斑检测[J]．长春理工大学学报(自然科学版),2018, 41(2):32-35, 40. [14] 郭媛,毛琦,陈小天,等 ．双波长剪切散斑干涉法在复合材料缺陷检测中的应用[J]．光子学报,2015, 44(3):188-192. [15] 李姝欣,杨馥,钟平,等 ．基于数字剪切散斑干涉的碳纤维复合材料层压板缺陷检测方法[J]．应用激光,2019, 39(5):872-879.
