Image processing method for radiographic testing of welding seams in engine nozzles
-
摘要: 针对火箭发动机喷管钎焊缝射线检测图像灰度分布不均匀、结构与缺陷信息混叠导致缺陷检测精度低的问题，提出一种基于边缘信息和结构特征提取的图像处理和缺陷分析方法。首先通过亮度矩阵、高斯滤波与锐化等方法对原始检测图像进行增强预处理；然后利用Canny算子和霍夫变换抽取图像中的边缘信息及边缘中的线段结构信息，并通过自适应阈值处理获取类正弦结构信息；最后对所得边缘信息、线段信息和类正弦结构信息进行差分处理并进行缺陷信息判定。基于所提算法开发了相应软件，对实际发动机喷管钎焊缝射线检测图像进行分析，处理结果表明，所提方法可有效克服区域灰度不均匀、结构与缺陷信息混叠等问题，实现了射线检测图像的统一处理和缺陷信息的提取，具有较高的检测效率及准确性。Abstract: A method for image processing and defect analysis based on edge information and structural feature extraction was proposed to address the problem of low defect detection accuracy caused by uneven grayscale distribution and overlapping structural and defect information in rocket engine nozzle brazing X-ray detection images. Firstly, quality enhancement preprocessing was performed on the original detection image through methods such as brightness matrix, Gaussian filtering, and sharpening; Then, the Canny operator and Hough transform were used to extract edge information and line segment structure information from the image, and the sine like structure information was obtained through adaptive threshold processing; Finally, differential processing was performed on the obtained edge information, line segment information, and sinusoidal like structure information, and defect information was determined. Based on the proposed algorithm, corresponding software was developed to analyze the actual radiographic inspection images of the engine nozzle brazing seam. The processing results showed that the proposed method can effectively overcome the effects of uneven regional grayscale, mixed information of structures and defects, and achieve unified processing of radiographic inspection images and extraction of defect information, with high detection efficiency and accuracy.
-
Keywords:
- radiographic testing image /
- image processing method /
- deep learning
-
-
[1] 刘贞, 任文坚, 彭东剑, 等.射线计算机成像技术在发动机变壁厚产品检测中的试验研究[J].宇航材料工艺, 2021, 51(6):85-88. [2] 江瑞柱, 闫志鸿, 白立来, 等.焊缝射线检测图像的缺陷搜寻与算法优化[J].电焊机, 2017, 47(8):38-43. [3] 雷铮强, 张丰, 林嵩, 等.管道环焊缝检测图像智能识别技术研究[J].管道技术与设备, 2022(3):36-40. [4] 姜文涛, 刘荣海, 杨迎春, 等.X射线数字影像尺寸测量软件开发与应用[J].软件, 2018, 39(5):207-211. [5] WICHTOWSKI B, HOŁOWATY J.Analysis of technological cracks in welded joints of railway bridges[J].Papers, 2021, 4(2):223-228.
[6] HWANG J, HWANG J.Image analysis for specific region segmentation of steel-tube radiographic images[J].ITC-CSCC:International Technical Conference on Circuits Systems, Computers and Communications, 2007, 9:44-47.
[7] 龚建良, 李鹏, 张正泽, 等.固体火箭发动机装药结构完整性研究进展[J].科学技术与工程, 2021, 21(2):434-441. [8] 徐翰文, 张闯, 陈苏婷.基于视觉显著性的图像特征提取算法[J].计算机应用, 2022, 42(2):72-78. [9] BHARODIYA A K, GONSAI A M.An improved edge detection algorithm for X-Ray images based on the statistical range[J].Heliyon, 2019, 5(10):2743.
[10] YAHAGHI E, MOVAFEGHI A, ROKROK B, et al.Defects detection of digital radiographic images of aircraft structure materials via geometric locally adaptive sharpening[J].Research in Nondestructive Evaluation, 2020, 31(2):107-115.
[11] 万书亭, 王萱, 张伯麟, 等.多幅X射线旋转图像轮廓对应点坐标提取和匹配方法研究[J].中国工程机械学报, 2022, 20(5):390-395. [12] 史先传, 许议元, 殷帅.基于机器视觉的摄像整纬纬斜检测研究[J].计算机测量与控制, 2023, 31(3):22-28. [13] 刘杰. 探究钢铁表面缺陷检测的研究与实现[J].中国设备工程, 2023(6):172-174.
