Ultrasonic detection and reconstruction of internal defects in metal cylinders
-
摘要: 超声检测既可检测金属柱状体工件的内部缺陷，亦可用于工件内部的缺陷重构和类型识别。为分析柱状工件内部缺陷的特征，提出了一种基于超声检测的金属柱状体的三维重构分析方法，采用有限元软件进行模拟，以得到金属柱状体工件内部的截面信号；然后通过B扫描成像对其像素点进行重组；最后利用体绘制技术对缺陷进行三维重构分析。试验结果表明，该方法可达到良好重构与分析金属柱状体工件内部缺陷的效果，允许误差满足要求。Abstract: Ultrasonic detection can not only detect the internal defects of metal cylinder workpiece, but also be used for defect reconstruction and type identification. In order to analyze the regularity and characteristics of the internal defects of the cylindrical workpiece, a three-dimensional reconstruction analysis method of the metal cylinder based on ultrasonic detection was proposed in this paper. The finite element software was used to simulate, so as to simulate the cross-section signal of the inside of the metal cylinder. It then its pixels were reassembled by using B-scan imaging. Finally, volume rendering technique was used to reconstruct the defects. The simulation results showed that this method can achieve good results in the reconstruction and analysis of the internal defects of the metal cylinder workpiece, and the allowable errors met the requirements.
-
-
[1] 顾雯琪, 王召巴, 陈友兴.基于轮廓线法的镁合金构件内缺陷三维反演方法研究[J]. 科学技术与工程, 2014, 14(30):206-208. [2] 陈友兴, 吴其洲, 刘蔺慧, 等.金属柱状体工件内缺陷超声检测的特征分析[J].火力与指挥控制, 2017, 42(9):158-161. [3] 金冬花, 刘展, 牛光明, 等. 探讨多模态三维体绘制重建在微血管减压术术前的评估价值[J]. 实用医学杂志, 2021, 37(9):1193-1198. [4] 易玮玮, 陈子轩, 徐泽楷, 等. 一种基于CPU的三维超声图像体绘制方法[J]. 生命科学仪器, 2019, 17(1):32-36, 31. [5] 刘昊. 基于数字图像处理的工件表面裂纹三维重构研究[D].长春:长春理工大学, 2012. [6] 刘永强, 杨世锡, 刘学坤. 基于激光超声的金属构件表面微裂纹定量检测技术研究[J]. 振动与冲击, 2019, 38(19):14-19. [7] 袁新安, 李伟, 殷晓康, 等. 基于ACFM的奥氏体不锈钢不规则裂纹可视化重构方法研究[J]. 机械工程学报, 2020, 56(10):27-33. [8] NAKAO M, KUREBAYASHI K, SUGIURA T, et al. Visualizing in vivo brain neural structures using volume rendered feature spaces[J].Computers in Biology and Medicine, 2014, 53:85-93.
[9] 陈自力, 陈友兴. 圆锥形物体超声自动检测系统设计[J].计算机测量与控制, 2013, 21(11):2947-2949. [10] 谢亮亮, 屠大维, 张旭, 等. 深海原位激光扫描双目立体视觉成像系统[J]. 仪器仪表学报, 2020, 41(6):106-114.
