Eddy current inspection of EMU hollow axles without coating removal
-
摘要: 动车组空心车轴外表面横向疲劳裂纹是典型的危害型缺陷，若未及时发现，可能引发断轴事故。提出了一种阵列涡流无损检测方法，其能在有300 μm厚漆层覆盖的情况下有效检出0.3 mm深人工裂纹，检测能力优于既有超声检测的1 mm深刻槽当量。该方法可融入既有动车组车轴无损检测流程，也可用于轴身等部位超声检测疑似缺陷的复核，具有较强的实用价值。Abstract: The transverse fatigue crack on the external surface of the hollow axle of EMU wasa typical hazard defect. If it is not detected in time, it may cause axle breaking accident. In this paper, an eddy current array inspection method wasproposed, which can effectively detect 0. 3 mm deep artificial crack under the condition of lacquer coating with 0. 3 mm thickness, and the detection ability wasbetter than the 1 mm deep groove equivalent of the existing ultrasonic flaw detection. This method can be integrated into the existing EMU axle flaw detection process, and used for the review of suspected defects in ultrasonic flaw detection, which have strong practical value.
-
Keywords:
- hollow axle /
- no coating removal /
- eddy current inspection
-
-
[1] 周庆祥, 傅晔, 詹发福, 等. 阵列涡流技术在车轴在役检测中的应用研究[J]. 金属加工:冷加工, 2016(1):399-400. [2] 黄凤英, 薛清涛, 李庆耀, 等.动车组空心轴内孔表面阵列涡流检测系统研发[J].高速铁路新材料, 2022, 1(4):52-56. [3] 徐可北, 周俊华.涡流检测[M].北京:机械工业出版社, 2004. [4] 郭德瑞.汽轮机叶片与叶根槽阵列涡流检测技术应用[J].中国设备工程, 2018(12):92-95. [5] 尹利, 尤永洪, 路凤玲, 等.阵列涡流检测性能验证技术研究[J].金属加工(热加工), 2022(6):114-116.
