Five-axis ultrasonic imaging detection system for copper-steel bonding layer defects in aerospace rotors
-
摘要: 针对现有的四轴平动扫描成像系统检测航空转子时系统定位精度低、抗干扰能力差的问题，研制了一套五轴超声成像检测系统。该系统对检测工作台，探头夹持装置及抗干扰装置进行了优化设计，改进了滤波方式，并在软件中加入探头对中算法。采用该系统进行抗干扰性试验，并对系统的定位精度进行验证，试验结果表明，五轴超声成像检测系统的定位精度高，成像效果好，能有效抑制电磁干扰，实现转子的连续稳定检测。Abstract: Aiming at the problems of low positioning accuracy and poor anti-interference ability of the existing four-axis translational scanning imaging system for detecting aeronautical rotors, a five-axis ultrasonic imaging detection system was developed. The system optimizes the design of the detection workbench, the probe clamping device and the anti-interference device, improves the filtering method, and adds the probe alignment algorithm into the software. The system is used for anti-interference testing, and the positioning accuracy of the system is verified.The experimental results show that the five-axis ultrasonic imaging detection system has high positioning accuracy, good imaging effect, can effectively suppress electromagnetic interference, and realize the continuous and stable detection of the rotor.
-
Keywords:
- ultrasonic inspection /
- aviation rotor /
- scanning imaging system
-
-
[1] 张锐, 陈以方, 付德永. 复合材料手动扫描超声特征成像检测[J]. 材料工程, 2003, 31(4):34-38. [2] 刘新, 陆铭慧, 陈以方, 等. 双金属转子复合层超声特征成像系统[J]. 无损检测, 2007, 29(6):309-311, 318. [3] 罗雪峰. 多转子连续扫描超声特征成像系统的研究[D]. 南昌:南昌航空大学, 2018. [4] 郭夏阳, 林建平, 孙博. 扩散焊技术的研究进展[J]. 热加工工艺, 2014, 43(17):15-20. [5] 梁永宽, 张智. 高速轴向柱塞泵搅拌和摩擦功率损失及空化分析[D]. 秦皇岛:燕山大学, 2020. [6] 王飞, 田玉清. 铜合金-钢双金属柱塞液压泵转子材料的研制[J]. 粉末冶金工业, 2013, 23(3):56-60. [7] 刘少杰, 张国伟, 王明杰. 铜/钢双金属泵体转子界面结合技术研究[J]. 热加工工艺, 2015, 44(7):73-77. [8] 陆铭慧, 朱毅, 刘勋丰. 结构特殊航空构件的超声特征扫描成像检测[C]//西南地区第十一次无损检测学术年会暨2011年(昆明)国际无损检测仪器展览会论文集. 昆明:国际无损检测仪器展览会, 2011. [9] CEPEDA-JIMÉNEZ C M, CARREÑO F, RUANOO A, et al. Influence of interfacial defects on theimpact toughness of solid state diffusion bonded Ti-6Al-4 V alloy based multilayercomposites[J]. Materials Science and Engineering:A, 2013, 563:28-35.
