在役高温蒸汽管道的交流电磁场检测

详细信息

ACFM detection of in-service high temperature steam pipeline

1. Linyi Special Equipment Inspection and Research Institute, Linyi 276000, China;
2. Luke Testing Equipment Co., Ltd., Jining 272000, China

摘要: 电站蒸汽管道系统长期处于高温、高压环境下,易产生裂纹等缺陷,甚至引发破坏性事故,而该类缺陷的常规无损检测方法局限性较大。基于交流电磁场检测技术,通过仿真研究工件表面电磁场变化规律,制作高温探头及试块并进行检测试验,验证该方法的有效性。试验结果表明,采用交流电磁场检测技术可以实现高温蒸汽管道的在线检测。
- ACFM /
- 高温 /
- 仿真 /
- 缺陷模拟
Abstract: The steam piping system of the power station has been in a high temperature and high pressure environment for a long time, which is prone to cracks and other defects and lead to destructive accidents. Conventional NDT methods are limited. Based on the ACFM, the variation law of the electromagnetic field on the surface of the workpiece is studied by simulation. High-temperature probes and test blocks are made and tested to verify the effectiveness of this method. The test results show that the on-line detection of high-temperature steam pipelines can be realized by using the ACFM.
- ACFM /
- high temperature /
- simulation /
- defect simulation

[1]	欧阳奇,张兴兰,陈登福,等.高温连铸坯表面缺陷的机器视觉无损检测[J].重庆大学学报(自然科学版),2007,30(11):27-31.
[2]	KOBAYASHI M,JEN C K,BUSSIERE J F,et al.High-temperature integrated and flexible ultrasonic transducers for nondestructive testing[J].NDT & E International,2009,42(2):157-161.
[3]	金彦枫,张惠芳,张峥,等.高温磁粉检测在压力容器制造中的应用[J].石油化工设备,2012,41(S1):48-50.
[4]	吕云腾.高温电涡流位移传感器分析与设计[D].杭州:浙江大学,2014.
[5]	魏双盈,郑世权,龚辉,等.连铸坯表面缺陷在线检测研究[J].武汉理工大学学报(信息与管理工程版),2009,31(3):433-436.
[6]	李久政,康宜华,孙燕华,等.基于信号源极值特征的钢管内外裂纹区分方法[J].华中科技大学学报(自然科学版),2008,36(12):75-78.
[7]	杨理践,毕大伟,高松巍.油气管道漏磁检测的缺陷量化技术的研究[J].计算机测量与控制,2009,17(8):1489-1491.
[8]	袁新安,李伟,李文艳,等.交流电磁场裂纹实时判定与评估方法[J].无损检测,2019,41(4):7-11,57.
[9]	李伟,基于交流电磁场的缺陷智能可视化检测研究[D].青岛:中国石油大学(华东),2007.
