AUT inspection of welding seam of cladded composite steel pipe
-
摘要: 分析了衬里复合材料的检测难点,基于相控阵AUT(自动超声检测)技术,制作了一系列焊接缺陷,并对比分析缺陷的AUT检测结果与缺陷宏观切片结果,评估AUT对于不同位置缺陷的检出率及缺陷定量精度,验证了衬里复合材料焊缝AUT检测的可靠性。Abstract: This paper analyzes the difficulties in the detection of lining composite materials. Based on the phased array AUT detection technology, a series of welding defects were made, and the AUT detection results of defects and the macro sectioning results of defects were compared and analyzed. The detection rate and quantitative accuracy of defects at different positions were evaluated, and the reliability of AUT detection of lining composite welds was verified.
-
Keywords:
- AUT /
- cladded composite material /
- detection precision
-
-
[1] 黄晶. 超声相控阵理论及其在海洋平台结构焊缝缺陷检测中的应用研究[D].上海:上海交通大学,2005. [2] 吴员,陈亮,张俊杰,等.海底管道无损检测技术评定的破坏性试验[J].无损检测,2019,41(11):34-35,47. [3] 陈亮.海底管道不锈钢复合管焊缝的全自动超声检测工艺认证[J].无损检测,2021,43(01):53-55. [4] 陈亮,孙晓明,尤卫宏,等.海底管线耐蚀合金环焊缝的AUT检测[J].无损检测,2015,37(2):44-46. [5] 陈亮,张立艳.AUT校准试块的制作和质量控制[J].无损检测,2017,39(2):64-66.
