Ultrasonic testing of vacuum brazed ring superalloy part
-
摘要: 以某封严环组件为研究对象，采用水浸超声检测技术，通过监测结合层处的超声回波幅值来分析检测分辨率和穿透力，进而评判真空钎焊结合质量。试验分析得出环状高温合金真空钎焊件的最佳检测参数，并将其运用于实际零件检测。检测结果表明，超声检测能及时发现焊接质量不良位置，具有一定的应用价值。Abstract: In this paper, a sealed ring assembly is taken as the experimental research object. By monitoring the ultrasonic echo amplitude at the bonding layer, the detection resolution and penetration force are analyzed, and the quality of vacuum brazing bonding is evaluated. The optimum testing parameters of annular superalloy vacuum brazing parts are obtained and applied to actual parts testing. The test results show that ultrasonic testing can find the position of poor welding quality in time, which has certain application value.
-
Keywords:
- vacuum brazing /
- ultrasonic testing /
- influence factor /
- testing parameter
-
-
[1] 刘武猛,郭纯,吴随松,等.高温合金焊接研究现状及发展趋势[J].金属加工(热加工).2022,(1):44-48. [2] 孙浩然,陆铭慧,伏翔,等. 双金属结合面缺陷的凸面相控阵超声检测[J].热加工工艺,2021,45(5):37-42. [3] 田春英,王军,陈龙,等. 真空钎焊GH3039高温合金大长径比管材套接结构工艺研究[J].热加工工艺.2021,50(15):40-44. [4] 张胜,侯金宝,郭德伦,等.K403合金高性能钎焊技术研究[J].航空材料学报,2006,26(3):327-328. [5] 郭凡, 郭鸿镇,王国庆,等.热处理制度对Ti-22Al-25Nb/Ti160双合金焊接盘组织和性能的影响[J].金属热处理,2016,41(8):85-88. [6] 罗鑫,姚泽坤,秦春,等.热处理对Ti-22Al-25Nb/TC11双合金焊接接头组织与性能的影响[J].金属热处理,2015,40(7):20-24. [7] 李晓红.先进航空材料和复杂构件的钎焊与扩散焊技术[J].电焊机,2008,38(9):38-40. [8] 卢超, 于润桥, 彭应秋. 焊接缺陷超声检测回波信号的双谱分析,2003, 18(1):57-61.
