Design of the profiling eddy current sensor for the tongue and groove of the engine blade
-
摘要: 针对特定的航空发动机涡轮叶片榫槽，设计了同心方形线圈仿形涡流传感器，在不同激励模式与激励频率下，对发动机叶片榫槽开展电磁学仿真检测试验。仿真结果表明，同心方形线圈传感器在激励频率为500 kHz与外线圈激励模式下，除了半径为0.05 mm，深为0.5 mm的圆形缺陷无法检出外，可以检测出长为1.0 mm，宽为0.2 mm或0.1 mm，深为0.5 mm或1.0 mm的4种纵向缺陷及半径为0.1 mm，深为0.5 mm或1.0 mm和半径为0.05 mm，深为1.0 mm的3种圆形缺陷。Abstract: In this paper, a concentric square coil profiling eddy current sensor is designed for a specific aero-engine turbine blade tongue and groove. Under different excitation modes and excitation frequencies, electromagnetic simulation tests are carried out on the engine blade tongue and groove. The simulation results show that under the excitation frequency of 500 kHz and the excitation mode of external coil, the concentric square coil sensor can detect four longitudinal defects with length of 1. 0 mm, width of 0. 2 mm or 0. 1 mm, depth of 0. 5 mm or 1. 0 mm, and three circular defects with radius of 0. 1 mm, depth of 0. 5 mm or 1. 0 mm, radius of 0. 05 mm and depth of 1. 0 mm. It was also found that the circular defects of radius of 0. 05 mm with depth of 0. 5 mm could not be detected.
-
-
[1] 王庆胜.航空发动机涡轮叶片缺陷检测中的关键技术研究[D].西安:西北工业大学,2005. [2] 刘滨春.涡轮盘榫槽槽底裂纹损伤分析[J].工程与试验,2008,48(4):27-29,40. [3] 郑杨.发动机榫头榫槽接触应力的有限元分析[J].现代工业经济和信息化,2017,7(15):17-18. [4] 陈希,王俊昌,胡春玲.航空发动机叶片榫头榫槽连接结构微动疲劳研究[J].科技风,2018(22):144-145. [5] 石剑,吕健.飞机发动机涡轮工作叶片榫头裂纹的原位涡流探伤[J].无损检测,2008,30(6):383-384,386. [6] 张丽,吴兴锁.航空发动机涡轮盘榫槽拉刀检测方法[J].计测技术,2009,29(4):31-32. [7] 刘铁.压气机轮盘叶片槽检测方法的改进[J].机械工程师,2010(6):124-125. [8] 谢小荣,江涛,杨小林.飞机发动机叶片榫槽爬波原位检测[J].无损检测,2012,34(1):31-33. [9] 江涛,龚春英,谢小荣.飞机发动机叶片榫槽超声爬波检测探头设计[J].机电产品开发与创新,2011,24(3):19-20,6. [10] 薛倩.飞机发动机叶片榫槽超声波检测探头设计[J].山东工业技术,2015(18):214. [11] 郑杨.发动机榫头榫槽接触应力的有限元分析[J].现代工业经济和信息化,2017,7(15):17-18. [12] 程军.碳纤维复合材料的电磁涡流无损检测技术研究[D].南京:南京航空航天大学,2015. [13] 张国才,谢小荣,刘永钊,等.叶片前缘仿形涡流检测仿真与试验设计[J].航空学报,2021,42(2):424678.
