板岩隧道中不同地质体的地质雷达图像特征

详细信息

GPR image characteristics of different geological bodies in slate tunnel

1. Yunnan Institute of Building Research Co., Ltd., Kunming 650223, China;
2. Geotechnical Engineering Technology Research Center of Yunnan Province, Kunming 650223, China

摘要: 以香丽高速公路板岩隧道为研究对象,通过雷达图像、开挖验证和掌子面地质素描对比分析,总结了板岩隧道中岩体完整、较破碎、破碎及富水时的地质雷达图像特征。提高了板岩隧道超前地质预报的准确性,有望为板岩隧道的超前预报提供参考依据,指导板岩隧道的施工。
- 板岩 /
- 超前地质预报 /
- 隧道地质素描 /
- 地质雷达
Abstract: This paper takes a slate tunnel of Xiangli expressway as the research background, through the comparison analysis of ground penetrating radar image, excavation verification and geological sketch of tunnel face, the characteristics of ground penetrating radar image under the four circumstances of the rock mass being complete, relatively broken, broken and rich in water are summarized in slate tunnel. The interpretation accuracy of advanced geological prediction of slate tunnel is improved, which provides a reference basis for advanced geological prediction and guides the construction of slate tunnel.
- slate /
- advanced geological prediction /
- geological sketch of tunnel /
- ground penetrating radar

[1]	王进.地质雷达在公路隧道超前地质预报中的应用[J].建筑技术开发,2020,47(24):68-69.
[2]	曹获,肖丽君,郑建东,等.雷达新技术检测隧道二次衬砌背后脱空[J].现代隧道技术,2002,39(5):58-62.
[3]	翟彦伟.探地雷达技术在公路路面质量检测中的应用[J].公路,2001,46(9):128-130.
[4]	邵珠山,张鹏举,张喆,等.隧道施工超前地质预报研究进展[J].长江科学院院报,2022,39(1):70-77,85.
[5]	王兆明.地下水对山岭隧道施工的影响及防治措施研究[J].工程建设与设计,2021(2):97-98.
