Characterization of each layer thickness of the bi-layer thin plates based on the cut-off frequency of the ultrasonic Lamb waves
-
摘要: 双层薄板材料在建筑、航空航天、镀膜等行业都有非常广泛的应用,厚度是板状材料的重要参数,因此对厚度进行表征具有重要意义。提出了一种基于超声Lamb波截止频率测量双层薄板各层厚度的方法,推导出双层薄板Lamb波截止频率与两板厚度比的关系,各层厚度可用总厚度和两板厚度比表征。通过理论公式计算了不同厚度比的双层薄板(非铝/铝)Lamb波一阶反对称模态(A1)的截止频率,得到A1模态截止频率随厚度比变化的曲线,并分析了非铝板横波速度对其变化的影响。Abstract: Bi-layer thin plates are widely used in the construction industry, aerospace, coating technology, etc. The thickness is an important parameter of slab materials, so the characterization of thickness is of great significance. This paper proposed a method for measuring the thickness of each layer of the bi-layer thin plates based on the cut-off frequency of ultrasonic Lamb waves. It was theoretically deduced that cut-off frequency of the bi-layer thin plates is related to the thickness ratio of the two plates. The thickness of each layer was characterized by the total thickness and the thickness ratio of the two plates. The cut-off frequencies of the first-order anti-symmetric mode (A1) of the bi-layer thin plates (non-aluminum/aluminum) with different thickness ratios were calculated by theoretical formulas, resulting in a curve of the A1 mode cut-off frequency with the thickness ratio of the two plates, and at the same time the effect of non-aluminum plate's transverse wave velocity on its change was analyzed.
-
Keywords:
- Lamb wave /
- cut-off frequency /
- bi-layer thin plate /
- A1 mode
-
-
[1] WANG M,ZHENG D D,XU Y.A new method for liquid film thickness measurement based on ultrasonic echo resonance technique in gas-liquid flow[J].Measurement,2019,146:447-457.
[2] LI Z J,HAN Z L,JIAN X H,et al.Pulse-echo acoustic properties evaluation method using high-frequency transducer[J].Measurement Science and Technology,2020,31(12):125011.
[3] 黄巧盛,周世圆,张翰明,等.基于自适应滤波的薄层厚度超声测量方法[J].中国测试,2019,45(10):34-39. [4] KRUGER S E,LORD M,MONCHALIN J P.Laser ultrasonic thickness measurements of very thick walls at high temperatures[J].AIP Conference Proceedings,2006,820(1):240-247.
[5] XIAO X,KONG T,QI H Y,et al.Nondestructive determination of film thickness with laser-induced surface acoustic waves[J].Chinese Physics B,2018,27(9):096802.
[6] CÈS M,CLORENNEC D,ROYER D,et al.Thin layer thickness measurements by zero group velocity Lamb mode resonances[J].The Review of Scientific Instruments,2011,82(11):114902.
[7] GRÜNSTEIDL C,BERER T,HETTICH M,et al.Determination of thickness and bulk sound velocities of isotropic plates using zero-group-velocity Lamb waves[J].Applied Physics Letters,2018,112(25):251905.
[8] GRÜNSTEIDL C,MURRAY T W,BERER T,et al.Inverse characterization of plates using zero group velocity Lamb modes[J].Ultrasonics,2016,65:1-4.
[9] CHO H,HARA Y,MATSUO T.Evaluation of the thickness and bond quality of three-layered media using zero-group-velocity lamb waves[J].Journal of Physics:Conference Series,2014,520:012023.
[10] 李春光.激光在铝板中激发零群速度Lamb波的研究[D].南京:南京理工大学,2018. [11] 熊继涛.激光超声换能器的导波检测应用研究[D].重庆:重庆大学,2019. [12] BALOGUN O,MURRAY T W,PRADA C.Simulation and measurement of the optical excitation of the S1 zero group velocity Lamb wave resonance in plates[J].Journal of Applied Physics,2007,102(6):064914.
[13] Ultrasonic Waves in Solid Media[M].Beijing:Science Press,2004.
