Analysis of analytical method of rectangular defects in pipeline magnetic field leakage internal detection
-
摘要: 针对现有漏磁场解析时假设磁荷均匀分布的计算结果与工程结果误差较大的问题,对管道缺陷磁化后磁荷的不均匀分布规律进行研究,得到了管道缺陷侧壁和棱线上的磁荷分布特征。基于磁偶极子理论建立了管道缺陷的三维磁偶极子解析模型,对缺陷棱线磁荷和侧壁非均匀面磁荷产生的漏磁场进行解算,并进行了试验研究。结果表明,计算结果与实际管道缺陷漏磁场的分布特征具有很好的一致性,误差小于假设磁荷均匀分布得到的漏磁场,说明所建模型可有效描述管道矩形缺陷漏磁场的分布特征。Abstract: Aiming to reduce the large error between the assumed uniform magnetic charge distribution in the analysis of leakage magnetic field and the actual engineering results, the non-uniform distribution law of magnetic charge after magnetization of pipeline defects was studied, and the distribution characteristics of magnetic charge on the side wall and edges of pipeline defects were obtained. Based on the magnetic dipole theory, the three-dimensional magnetic dipole analytical model of pipeline defect was established, the leakage magnetic field generated by the edge magnetic charge of the defect and the magnetic charge of the non-uniform surface of the side wall was solved, and the experimental research was carried out. The calculation results and the actual defect leakage magnetic field distribution characteristics of pipeline were in very good consistency, and the actual error of the leakage magnetic field was smaller than that while the distribution of magnetic charge being assumed uniform. It is shown that the model can effectively describe the distribution characteristics of leakage magnetic field with rectangular defects.
-
Keywords:
- magnetic dipole /
- wall defect /
- defect leakage magnetic field
-
-
[1] 杨理践,耿浩,高松巍.长输油气管道漏磁内检测技术[J].仪器仪表学报,2016,37(8):1736-1746. [2] KIM H M,PARK G S.A study on the estimation of the shapes of axially oriented cracks in CMFL type NDT system[J].IEEE Transactions on Magnetics,2014,50(2):109-112.
[3] 苏志毅,黄松岭,赵伟,等.油气管道缺陷漏磁检测地面标记器研制[J].无损检测,2012,34(10):16-18,50. [4] ZHANGH,LIAO L,ZHAO R Q,et al.The non-destructive test of steel corrosion in reinforced concrete bridges using a micro-magnetic sensor[J].Sensors,2016,16(9):1439.
[5] 吴德会,刘志天,王晓红,等.表面缺陷的方向性对漏磁场分布的影响[J].物理学报,2017(4):266-276. [6] 杜志叶,阮江军,余世峰,等.油管漏磁检测的有限元建模技术研究[J].中国电机工程学报,2007,27(27):108-113. [7] 时朋朋.缺陷漏磁场磁偶极子模型的若干解析解[J].无损检测,2015,37(3):1-7. [8] LI C J,CHEN C,LIAO K X.A quantitative study of signal characteristics of non-contact pipeline magnetic testing[J].Insight-Non-Destructive Testing and Condition Monitoring,2015,57(6):324-330.
[9] 李忠吉,李长俊,成婷婷,等.埋地管道缺陷的自漏磁场计算方法研究[J].中国安全生产科学技术,2019,15(9):153-157. [10] 仲维畅.方钢纵向磁化时各棱上的磁荷线密度[J].无损检测,2002,24(8):332-335. [11] 仲维畅.磁偶极子理论在无损检测中的用途[J].无损检测,2010,32(1):49-52. [12] 李红梅,李云飞,陈振茂,等.电磁无损检测中的自然磁化分布反演方法——双层平面分布磁荷重构[J].无损检测,2011,33(9):33-36,39. [13] 吕绍旭,张春才,宋志强.管道漏磁检测探头提离效应仿真分析[J].后勤工程学院学报,2015,31(5):41-45.
