压力管道未焊透深度的数字射线定量检测

详细信息

Digital radiography quantitative detection of incomplete penetration depth of pressure pipeline

1. Shaoxing Key Laboratory of Special Equipment Intelligent Testing and Evaluation, Shaoxing Special Equipment TestingInstitute, Shaoxing 312071, China;
2. Jiasheng Test Engineering Co., Ltd., Beijing 100016, China

摘要: 针对压力管道定期检验中常见的未焊透缺陷,分析了国内外标准关于未焊透深度检测的相关规定和研究现状,提出了一种基于DR (数字X射线摄影) 技术的未焊透深度检测方法,并用其对阶梯试块、内壁有刻槽的管道和外壁有刻槽的管道等3个模拟试件进行检测,检测深度的最大偏差为10.0%。将该方法用于工程检测,结果表明DR技术可以实现未焊透深度的定量检测,为工业管道的安全评级奠定了基础。
- 未焊透 /
- 对比试块 /
- 数字X射线摄影 /
- 深度检测
Abstract: Aiming at the common incomplete penetration defects in the periodic inspection of pressure pipeline, the relevant provisions and research status of incomplete penetration depth detection in domestic and foreign standards are analyzed, and an incomplete penetration depth detection method based on DR (digital radiography) technology is proposed and used to detect three simulation specimens, such as stepped test block, pipes with grooves on the inner wall and on the outer wall. The maximum deviation of the measured depth is 10.0%. The results show that DR technology can realize the quantitative detection of incomplete penetration depth, which lays a foundation for the safety rating of industrial pipelines.
- incomplete penetration /
- reference block /
- digital radiography /
- depth detection

[1]	王海锋,郭涛,周海彦.在用含未焊透缺陷工业管道的安全评定[J].管道技术与设备,2021(1):6-8.
[2]	韩树新,郑翔宇,金志江,等.含未焊透缺陷工业压力管道的安全性试验研究[J].轻工机械,2008,26(4):103-106.
[3]	王飞,蒋诚航,许根富,等.内压、弯矩组合载荷作用下未焊透管道的安全评价方法研究[J].中国安全生产科学技术,2016,12(4):180-184.
[4]	吕锋杰,张权良.射线检测中对比试块法测定缺陷高度的准确性探讨[J].特种设备安全技术,2020(1):56-58.
[5]	杨玲,富阳.未焊透数字射线定量检测研究[J].锅炉制造,2015(6):43-46.
[6]	郭黎群,周波,许林涛.管道未焊透深度测定研究[J].无损探伤,2011,35(1):16-18.
[7]	黄明海,周长友,徐广奎,等.在役管道腐蚀坑深度的DR检测[J].无损检测,2021,43(6):16-18,78.
[8]	郭文明,陈宇亮.X射线图像灰度值与透照厚度的定量关系[J].无损检测,2016,38(2):14-17,59.
[9]	赵俊生,马朝阳,张心荣.压力管道腐蚀深度的数字射线成像检测[J].无损检测,2021,43(6):45-49.
