电站锅炉小径管坡口未熔合缺陷的检出率分析

基金项目:

福建省质量技术监督局科技项目(FJMS2020017)

详细信息

Detection rate analysis of imcomplete fusion defect in small diameter pipe groove of power plant boiler

摘要: 对某电站锅炉空间受限区域的小径管进行相控阵超声检测和射线检测,并对检测结果进行对比分析。分析结果表明,相控阵超声检测对坡口未熔合缺陷的检出率明显高于射线检测的检出率,可以有效提升焊接质量,避免缺陷漏检带来的危害。
- 小径管 /
- 射线检测 /
- 相控阵 /
- 未熔合
Abstract: Phased array ultrasonic testing and radiographic testing were carried out on small diameter tubes in the confined space of a power plant boiler, and the test results were compared and analyzed. It was shown that the detection rate of incomplete fusion defects in groove by phased array ultrasonic testing was significantly higher than that by radiographic testing, which may effectively improve the welding quality and avoid the hazards caused by defect omission.
- small diameter pipe /
- radiographic testing /
- phased array /
- imcomplete fusion

[1]	刘毅辉,牛永吉,王郑钢.锅炉小径管射线检测与相控阵检测的对比分析[J].无损检测,2018,40(4):45-49.
[2]	刘佳,赵远.集箱管排小径管超声相控阵及射线检测对比分析[J].焊接与检测,2018(8):52-54.
