粉末高温合金微缺陷的超声环形阵列全聚焦成像检测

基金项目:

国家自然科学基金资助项目（50515449，52075049）

详细信息

Ultrasonic annular array total focusing imaging inspection ofmicro-defects in powder metallurgy superalloy

1. AECC Beijing Institute of Aeronautical Materials, Beijing 100095, China;
2. Beijing Key Laboratory of Aeronautical Materials Testing and Evaluation, Beijing 100095, China;
3. Key Laboratory of Materials Testing and Evaluation, Aero Engine Corporation of China, Beijing 100095, China;
4. School of Materials Science and Engineering, Beihang University, Beijing 100191, China

摘要: 为了满足大厚度粉末高温合金零件的高灵敏度检测需求，提出了基于超声环形阵列的全聚焦成像检测方法。从检测灵敏度、信噪比和近表面分辨力3个方面入手，验证了该检测方法的可行性。与常规相控阵多深度聚焦检测方法进行试验对比，结果表明，该方法在灵敏度一致性、近表面分辨力等方面具有显著优势，可为粉末高温合金微缺陷的检测提供一种先进可行的技术。
- 粉末高温合金 /
- 全聚焦方法 /
- 环形阵列
Abstract: For the high-sensitivity inspection requirements of large-thickness parts of powder metallurgy superalloy, total focusing method using ultrasonic annular array was proposed. The feasibility of the method has been verified from the detection sensitivity, signal-to-noise ratio and near-surface resolution. Comparative experiments have been carried out with the multi-depth focusing method of conventional phased array technique and it shows that total focusing method has significant advantages in consistency of detection sensitivity and near-surface resolution. The research work provides an advanced and feasible technology for the detection of micro-defects in powder metallurgy superalloys.
- powder metallurgy superalloy /
- total focusing method /
- annular array

[1]	胡连喜, 冯小云.粉末冶金高温合金研究及发展现状[J].粉末冶金工业, 2018, 28(4):1-7.
[2]	孙志坤, 吕日红, 于冬.粉末高温合金盘件超声波底损监控问题探讨[J].物理测试, 2019, 37(6):27-31.
[3]	梁菁, 史亦韦.多区聚焦技术在粉末高温合金微缺陷检测中的应用[J].航空材料学报, 2006, 26(3):144-147.
[4]	DRINKWATER B W, WILCOX P D.Ultrasonic arrays for non-destructive evaluation:a review[J].NDT & E International, 2006, 39(7):525-541.
[5]	HOLMES C, DRINKWATER B, WILCOX P.The post-processing of ultrasonic array data using the total focusing method[J].Insight-Non-Destructive Testing and Condition Monitoring, 2004, 46(11):677-680.
[6]	赖溥祥, 张碧星, 汪承灏.环形相控阵换能器辐射和反射声场[J].声学学报, 2007, 32(3):212-220.
[7]	沙正骁, 梁菁, 李彦.基于超声环阵相控阵的变孔径聚焦检测技术[J].失效分析与预防, 2019, 14(2):84-89, 95.
[8]	HOLMES C, DRINKWATER B W, WILCOX P D.Post-processing of the full matrix of ultrasonic transmit-receive array data for non-destructive evaluation[J].NDT & E International, 2005, 38(8):701-711.
[9]	杨敬, 吴斌, 焦敬品, 等.各向异性焊缝缺陷超声阵列全聚焦成像方法[J].声学学报, 2019, 44(1):125-135.
[10]	李文涛, 周正干, 李洋.环形阵列超声换能器的全聚焦成像方法及其应用[J].航空学报, 2020, 41(10):423657.
