挤压棒材的机器人超声无损检测系统

基金项目:

广东省潮州市科技计划项目（2019ZX16）；山西省科技重大专项项目（20201102003）

详细信息

Robotic ultrasonic nondestructive testing system for extruded bars

1. School of Mechanical Engineering, Zhejiang University, Hangzhou 310027, China;
2. Guangdong Huaxing Heat Exchange Equipment Co., Ltd., Chaozhou 515000, China

摘要: 针对挤压棒材检测效率低的问题，分析了挤压棒材的检测难点，提出了一种挤压棒材的机器人超声无损检测系统。该系统从功能上可以分为被检件的运动控制与超声检测两部分。经试验验证，该系统能准确识别挤压棒材中的缺陷，不仅检测速度快，而且工作效率高，具有较大的应用前景。
- 金属材料 /
- 超声检测 /
- 挤压棒材 /
- 机器人
Abstract: Aiming at the problem of low detection efficiency of extruded bars, this paper analyzes the difficulties of extruded bar inspection and a robotic ultrasonic nondestructive testing system for extruded bars is therefore proposed. The system can be functionally divided into two parts: motion control of the test piece and ultrasonic testing. After experimental verification, the system can accurately identify the defects in the extruded bars with high efficiency and fast detection speed, which has a greater application prospect.
- metallic material /
- ultrasonic testing /
- extruded bar /
- robot

[1]	刘永亮, 李耀群.铜及铜合金挤压生产技术[M].北京:冶金工业出版社,2007.
[2]	刘智勇, 祁向荣,林卓毅.铝型材挤压模超声水浸检测的设计与实现[J].轻工科技,2013,29(9):142-143.
[3]	李湘海. 铜合金产品缺陷的超声定性检测[J].无损检测,2006,28(3):153-156.
[4]	魏志丽, 林燕文.工业机器人应用基础-基于ABB机器人[M].北京:北京航空航天大学出版社,2016.
[5]	谭芳. ABB IRB120型工业机器人编程及搬运实例[J].南方金属,2019(2):43-46.
[6]	丁辉, 张俊,张益成,等.超声检测声场计算模型的建立与仿真软件的开发[J].无损检测,2009,31(8):614-618.
