TOFD testing signal noise reduction technology for stainless steel welds based on depth resampling superposition
-
摘要: 奥氏体不锈钢焊缝粗大的柱状晶组织会导致常规TOFD（超声波衍射时差法）检测信号的信噪比较低，检测信号中的缺陷衍射波较难判定。为提高检测信号信噪比，基于缺陷衍射波信号与焊缝组织结构噪声的差异，提出了深度重采样叠加算法并进行检测试验。研究结果表明，与缺陷衍射波信号基本一致的相位分布相比，结构噪声的相位分布具有随机性；深度重采样叠加技术可有效抑制组织结构噪声，提高检测信号信噪比，对于提高奥氏体不锈钢焊缝的TOFD检测能力具有重要作用。Abstract: The coarse columnar crystal structure of the austenitic stainless steel weld leads to the low signal-to-noise ratio of the conventional TOFD detection signal, and it is difficult to determine the defect diffraction wave in the detection signal. In order to improve the signal-to-noise ratio of the detection signal, based on the difference between the defect diffraction wave signal and the weld structure noise, a deep resampling and superposition algorithm is proposed and a test is carried out.The research results show that, compared with the phase distribution of the defect diffraction wave signal, the phase distribution of the structure noise is random; the deep resampling superposition technology can effectively suppress the structure noise of the tissue and improve the signal-to-noise ratio of the detection signal, playing an important role in improving the TOFD inspection ability of austenitic stainless steel welds.
-
Keywords:
- depth resampling /
- TOFD testing /
- austenitic stainless steel /
- signal-to-noise ratio
-
-
[1] 唐浩伟, 罗林.超声TOFD图像的噪声杂波抑制研究[J].电子制作,2020(7):44-47. [2] 谢雪. 提高压力容器焊缝TOFD检测分辨率方法的研究[D].大连:大连理工大学,2015. [3] 郑中兴. 奥氏体不锈钢焊缝的超声探伤方法[J].无损探伤,2005,29(4):12-16. [4] 孙旭, 金士杰,张东辉,等.基于自回归谱外推的小尺寸裂纹TOFD定量检测[J].无损检测,2017,39(10):8-11. [5] 刚铁, 迟大钊,袁媛.基于合成孔径聚焦的超声TOFD检测技术及图像增强[J].焊接学报,2006,27(10):7-10,113. [6] 陈尧, 冒秋琴,石文泽,等.基于相位相干性的厚壁焊缝TOFD成像检测研究[J].机械工程学报,2019,55(4):25-32. [7] CHEN Y,LUO Z B,ZHOU Q,et al.Modeling of ultrasonic propagation in heavy-walled centrifugally cast austenitic stainless steel based on EBSD analysis[J].Ultrasonics,2015,59:31-39.
[8] ZHANG S Z,LI X B,JEONG H,et al.Theoretical and experimental investigation of the pulse-echo nonlinearity acoustic sound fields of focused transducers[J].Applied Acoustics,2017,117:145-149.
