基于CIVA仿真的核电主蒸汽管道对接焊缝的超声成像复合检测

基金项目:

国家自然科学基金资助项目（61701544）；国家市场监管总局科技计划项目（2017QK089）

详细信息

Ultrasonic imaging composite testing of butt weld in nuclear power VVP based on CIVA simulation

1. Ningbo Branch of Petrochemical Engineering Quality Supervision Station, Ningbo 315207, China;
2. China Nuclear Power Engineering Co., Ltd., Shenzhen 518124, China;
3. China Special Equipment Inspection and Research Institute, Beijing 100029, China;
4. Key Laboratory of Nondestructive Testing and Evaluation of SAMR, Beijing 100029, China

摘要: 对某核电厂的VVP（主蒸汽管道系统）对接焊缝进行了PAUT（相控阵超声检测）与TOFD（超声波衍射时差法）仿真检测工艺分析，使用模拟试块对分析后得到的复合检测工艺进行验证，验证结果表明，该复合工艺检测效果良好，给VVP管道对接焊缝的检测提供了一个新的思路。
- 超声成像 /
- 复合工艺 /
- 相控阵超声检测(PAUT) /
- 超声波衍射时差法(TOFD)
Abstract: In this paper, the simulation process of PAUT and TOFD for butt weld of VVP pipeline system in a nuclear power plant is analyzed and studied, and the composite detection process is verified on the simulation test block. The test results show that the composite process has good detection effect, which provides a new idea for VVP pipeline butt weld inspection.
- ultrasonic imaging /
- composite process /
- phased array ultrasonic testing (PAUT) /
- time of flight diffraction (TOFD)

[1]	聂凯. 核电站VVP系统管道焊缝超声检测技术研究[J].科技创新导报,2019,16(8):83-85.
[2]	田绍伟, 刘春雨,王大庆,等.PAUT在长输天然气管道环焊缝检测中的应用实践[J].石油工业技术监督,2020,36(6):36-39.
[3]	姚利君, 李华良,管文.相控阵超声成像法检测钢筋混凝土叠合构件缺陷研究[J]. 施工技术,2017,46(17):20-22,44.
[4]	鲁金忠, 季仕杰,吴刘军,等.激光冲击-超声滚压复合工艺对AZ91D镁合金力学性能的影响[J].吉林大学学报(工学版),2020,50(4):1301-1309.
