Application and prospect of industrial CT imaging technology in remanufacturinginterface typical defects research
-
摘要: 介绍了工业计算机断层扫描技术（CT）成像技术的基本原理、组成和关键性能指标，激光熔覆增材再制造界面典型缺陷的形成机理，以及工业CT成像技术在再制造典型缺陷研究中的应用情况。针对激光熔覆增材再制造界面缺陷的特点，提出了工业CT成像技术在再制造界面缺陷分析中的研究难点，最后展望了工业CT成像技术在再制造界面典型缺陷研究中的应用前景。Abstract: The basic principle, components and the key performance of industrial computed tomography (CT) imaging technology are introduced in this work. The presentation also includes mechanism of internal defect in parts remanufactured by laser cladding technology and the practical application of industrial computed tomography in the detection of defects such as crack, voids and inclusions. In allusion to interface defect in parts remanufactured by laser cladding technology, research difficulty and prospect for application of industrial CT technique in detecting the defects in remanufacturing interface are discussed.
-
Keywords:
- industrial computed tomography /
- laser cladding /
- remanufacturing interface /
- defect
-
-
