Ultrasonic detection of RTM forming process composites which containing thermoplastic yarn
-
摘要: 对一种含热塑性纱线的复合材料树脂传递模塑（RTM）工艺成型层压板进行A扫描和C扫描检测，结合金相检验结果，分析其与不含热塑性材料的RTM工艺成型层压板的超声检测结果差异。建立了适用于含有该种材料的碳纤维复合材料的超声检测方法和特征缺陷判定方法。结果表明，接触式超声反射法能有效、直观地检测该种层压板的内部质量，且与金相检验结果相符合。Abstract: Ultrasonic A-scan and C-scan testing combined with metallographic detection was carried out for a composite material containing thermoplastic yarn layer board which was manufactured by resin transfer molding (RTM) process. The difference of ultrasonic testing results between RTM forming process layer board with or without thermoplastic materials was analyzed. The aim of the research is to establish ultrasonic detection method and characteristics of carbon fiber composite material defect judgment method suitable for this kind of material. The result shows that the contact ultrasonic reflection method can effectively and directly reflect the internal quality of the layer board, and it is consistent with the metallographic detecting results.
-
Keywords:
- thermoplastic /
- RTM process /
- metallographic detection /
- ultrasonic detection
-
-
[1] 李婷, 刘建军,杨学军,等.一种RTM用耐烧蚀改性酚醛树脂性能研究[J].玻璃钢/复合材料,2015(7):18-21. [2] 阎龙, 史耀耀,段继豪,等.先进树脂基复合材料制造技术综述[J].复合材料低成本制造技术,2011(3):55-58. [3] 张惠玲. 碳纤维复合材料主要缺陷无损检测和识别研究[D].长沙:国防科学技术大学,2013. [4] 史亦伟. 超声检测[M].北京:机械工业出版社,2005. [5] 陈一萌. Pb/EPOXY声阻抗梯度复合材料制备与声学特性研究[D].哈尔滨:哈尔滨工业大学,2017.
