阀套Cr12MoV磁粉检测的磁痕显示

详细信息

Magnetic particle indication on magnetic particle testing for valve sleeve (Cr12MoV)

1. Sichuan Keyuan Testing Center of Engineering Technology, Chengdu 610091, China;
2. Sichuan Aerospace Changzheng Equipment Manufacturing Co., Ltd., Chengdu 610100, China;
3. Sichuan Aerospace Fenghuo Servo Control Technology Co., Ltd., Chengdu 611130, China

摘要: 某阀套（材料Cr12MoV）的磁粉检测过程中，内壁出现线性磁痕显示。经过荧光渗透检测复验与磁粉检测复验，结合金相检验结果，对形成内壁线性磁痕的原因进行了分析。结果表明，组织中存在的碳化物带状偏析条带是磁粉检测时出现线性磁痕显示的原因。
- 阀套 /
- 偏析 /
- 磁粉检测 /
- 磁痕
Abstract: The linear magnetic particle indication was detected on the inner wall surface of valve sleeve (Cr12MoV) in magnetic particle testing process,and the reason of inducing such indication was analyzed by the reinspection of fluorescent penetrant testing and the reinspection of magnetic particle testing and metallographic examination. The results show that the linear indication was caused by carbide zonal segregation of banded structure in the microstructure.
- valve sleeve /
- segregation /
- magnetic particle testing /
- magnetic particle indication

[1]	侯彩云, 宗铎, 王志忠, 等. Cr12MoV模具断裂原因分析[J].热加工工艺,2010,39(20):198-200.
[2]	叶代平, 苏李广.磁粉检测[M].北京:机械工业出版社,2004.
[3]	叶代平. 磁粉检测[M].北京:机械工业出版社,2019.
[4]	宋志哲. 磁粉检测[M].北京:中国劳动社会保障出版社,2007.
[5]	韩艳春. 440C材料零件表面特殊磁痕的原因分析[J].无损检测,2014,36(3):39-41.
