钢轨探伤车对钢轨焊缝缺陷的检测能力

基金项目:

中国铁道科学研究院集团有限公司基金资助项目（2020YJ059）

详细信息

Steel rail weld defect inspection ability of steel rail flaw detection vehicle

1. Infrastructure Inspection Research Institute, China Academy of Railway Science Co., Ltd., Beijing 100081, China;
2. Railway Infrastructure Inspection Center, China State Railway Group Co., Ltd., Beijing 100081, China

摘要: 为了验证钢轨探伤车对焊缝缺陷的检测能力，设计了人工模拟焊缝缺陷，分别以不同速度对钢轨进行检测。结果表明，在钢轨探伤车检测工艺能够覆盖的有效检测区域内，人工模拟焊缝缺陷的平均检出率为97.2%，其中轨头、轨腰中φ 5 mm横通孔当量的体积型缺陷的检出率为100%，轨颚处φ 3 mm横通孔当量的体积型缺陷的检出率为91.7%。检测结果可为同行提供参考。
- 超声波 /
- 钢轨探伤车 /
- 焊缝 /
- 轮式探头
Abstract: In order to verify the steel rail weld defect inspection ability of rail flaw detection vehicle, artificial weld defects are designed and tests of different steel rail are carried out. Test results show that within the weld effective detection area which can be covered by the flaw detection technology of rail flaw detection vehicle, the average detection rate of artificial weld defects is 97. 2%. The defect detection rate of φ 5 mm cross hole equivalent volume defects at the rail head and waist is 100%, and φ 3 mm cross hole equivalent volume defects at the rail jaw is 91. 7%. The test results can be used as a reference for peers.
- ultrasonic wave /
- steel rail flaw detection vehicle /
- weld /
- wheel probe

[1]	田常海. 大秦重载铁路75 kg/m钢轨伤损特点及规律[J].铁道工程学报,2019,36(1):38-42,53.
[2]	袁学勇. 智能型移动式钢轨气压焊接设备的研制[D].大连:大连交通大学,2008.
[3]	铁路职工岗位培训教材编审委员会. 钢轨探伤工[M].北京:中国铁道出版社,2010.
[4]	李培, 王旭,石永生,等.高速轮式钢轨探伤变距式超声波发射模式的设计与应用[J].铁道建筑,2015,55(11):127-130,146.
