工业计算机断层成像几何尺寸测量不确定度评定

详细信息

Uncertainty determination for dimensional measurements with industrialcomputed tomography

Institute of Applied Electronics, Chinese Academy of Engineering, Mianyang 621900, China

摘要: 介绍了一种基于试验的工业计算机断层成像（CT）尺寸测量不确定度的评定与分析方法，通过一系列重复测量，获得了工业CT尺寸测量不确定度分量和扩展不确定度，所有测量结果均位于亚像素范围，系统误差是试验主要的不确定度分量，可以满足实际应用中对工业CT尺寸测量不确定度评定的要求。
- 工业CT /
- 尺寸测量 /
- 不确定度评定
Abstract: This paper presents a method to determine the uncertainty of dimensional measurements with industrial computed tomography (CT) based on experimental evaluation method. Subsequently, some of the uncertainty budget and the expanded uncertainty are quantified based on a series of measurements. The uncertainty in measurement is within the sub-pixel region for all measures. The systematic bias is the main contributor for all measurement results. The results show that the proposed method can be a suitable approach for CT measurement uncertainty assessment in practical applications.
- industrial computed tomography /
- dimensional measurement /
- uncertainty determination

[1]	JIANG H. 计算机断层成像技术-原理、设计、伪像和进展[M].张朝宗,译.北京:科学出版社,2006.
[2]	DE C L, CARMIGNATO S, KRUTH J P. Industrial applications of computed tomography[J]. CIRP Annals-Manufacturing Technology, 2014, 63(2):655-677.
[3]	DEWULF W, KIEKENS K, TAN Y. Uncertainty determination and quantification for dimensional measurements with industrial computed tomography[J]. CIRP Annals-Manufacturing Technology,2013,62(1):535-538.
[4]	BARTSCHER M, ILLEMANN J, NEUSCHAEFER-RUBE U. ISO test survey on material influence in dimensional computed tomography[J].Case Studies in Nondestructive Testing and Evaluation, 2016, 6(11):79-92.
[5]	付康,倪培君,唐盛明,等.基于工业CT线性尺寸测量的不确定度分析[J].强激光与粒子束,2018,30(5):1-6.
[6]	苏宇航,王倩妮,何方成.已校准量块的工业CT测量不确定度分析[J].无损检测,2016,38(2):28-31.
