The influence of sensor lift height on transient electromagnetic signal
-
摘要: 研究了提离高度对瞬变电磁法检测的影响，制作了传感器装置，搭建了试验平台，设计了试验方案。结果表明：提离高度在有效范围内只影响信号的幅值，而对信号衰减曲率几乎无影响，对于厚度分别为5，10，15 mm的试件，在有效提离高度为100 mm和大于100 mm时，验证了传感器有效覆盖范围为400 mm；厚度为20 mm试件的试验数据可以表明该传感器的适用范围；瞬变电磁法传感器位置的上下浮动对评价结果无影响。试验结果为实际工况中非开挖腐蚀检测器的设计、脉冲涡流探头的优化及腐蚀评估的准确性提供了参考价值。Abstract: In order to study the influence of lift height on transient electromagnetic detection technology, a sensor device together with a test platform was built and the test plan was correspondingly designed. The results show that the effective lift height for test piece of thickness being 5 mm, 10 mm and 15 mm is 100 mm. The effective attenuation height of the received signal is constant. When the lift height is greater than 100 mm, the effective coverage of the sensor is verified to be 400 mm. For the experimental data of the thickness of the 20 mm test piece, the applicable range of the sensor is known. It is determined that the floating position of the transient electromagnetic sensor has no influence on the evaluation result. The test result provides reference value for the design of the non-excavation corrosion detector, the optimization of the pulsed eddy current probe and the corrosion evaluation accuracy in the actual working condition.
-
Keywords:
- sensor /
- lift height /
- curvature /
- amplitude
-
-
[1] 张涛,赵弘,王维斌,等.基于响应面法的瞬变电磁法聚焦线圈优化设计[J].电子测量技术,2016,39(7):28-32,38. [2] 汪路路,于润桥,胡博,等.基于瞬变电磁法的城市热力管道腐蚀检测[J].无损检测,2019,41(7):34-38. [3] 张莹莹,李貅.地空瞬变电磁法研究进展[J].地球物理学进展,2017,32(4):1735-1741. [4] 陈禄尧. 瞬变电磁法输油管道腐蚀内检测方法研究[D].西安:西安石油大学,2019. [5] 张涛. 基于电磁感应对埋地金属管道缺陷非开挖检测技术研究[D].北京:中国石油大学,2017. [6] 党娜,王维斌,张涛,等.管道腐蚀脉冲涡流检测的三维仿真与试验[J].无损检测,2017,39(2):57-60,74. [7] 张涛.基于脉冲涡流对埋地金属管道缺陷定量算法研究[J].电子测量技术,2018,41(20):28-31.
