基于X射线计算机辅助成像技术的带料管道焊缝检测

基金项目:

浙江省质监系统质量技术基础建设项目（20180119）

详细信息

Weld detection of pipeline with medium based on X-ray computed radiographic technology

1. Ningbo Special Equipment Inspection and Research Institute, Ningbo 315048, China;
2. Ningbo Labor Safety and Technology Services Company, Ningbo 315048, China

摘要: 采用便携式数字CR系统对某大型石化企业的400条压力管道进行了X射线计算机辅助成像检测（CR）。通过设置管道是否带料、采用不同射线源和是否考虑介质对透照的影响等三种情况的比对试验，验证了检测手段的可靠性及有效性。现场检测能发现管道对接焊缝的未焊透、未熔合、夹渣、气孔和裂纹等典型缺陷，并针对CR现场应用存在的一些问题进行了讨论，为CR技术在带料管道焊缝检测中的广泛应用奠定基础。
- CR /
- 压力管道 /
- 对接焊缝 /
- 焊接缺陷
Abstract: Using the portable digital CR system, the X-ray computer-aided image detection (CR) of 400 pressure pipelines in a large petrochemical enterprise was carried out. The reliability and effectiveness of the detection method are verified by the comparison test of whether the pipeline is equipped with medium, using different ray sources and considering the influence of the medium on the permeation. The typical defects of butt weld of pipeline, such as incomplete penetration, incomplete fusion, slag inclusion, air hole and crack, can be found in the field inspection. Some problems existing in the field application of CR are discussed, which lays a certain foundation for the wide application of CR technology in the inspection of weld seam of pipeline with medium.
- CR /
- pressure pipeline /
- butt weld /
- welding defect

[1]	张辉宇,张瑞轩. CR检测技术在长输管道上的应用[J]. 无损检测, 2016,38(8): 60-64.
[2]	孙朝明,孙忠诚,曾祥照.数字射线成像中归一化信噪比指标的分析讨论[J]. 无损检测, 2017,39(10): 42-48.
[3]	王彬,华雄飞,钟华,等.计算机射线照相(CR)分辨率对图像质量的影响[J]. 中国电力, 2016,49(4): 149-153.
[4]	周锐.国内外X射线数字成像检测技术标准比对研究[D]. 太原:中北大学, 2013.
[5]	张万岭,张晓峰,林启峰.计算机射线成像(CR)系统及工业应用[J]. 无损探伤, 2011,35(3): 34-36.
