全聚焦相控阵技术的场测量

详细信息

Field measurement of full focus phased array technology

摘要: 全聚焦相控阵系统不能显示A扫，从而给检测带来问题。通过研究全聚焦相控阵的声场特性和信号特性，提出“场测量”技术路线，阐述了有关原理和实施的基本过程，论证了在焊缝检测应用中的可行性，给出了一些试验结果。结果表明：场测量技术路线有利于全聚焦相控阵技术优势的发挥，在检测中的应用效果良好。
- 全聚焦相控阵 /
- 焊缝检测 /
- 声场特性 /
- 场测量 /
- 信噪比
Abstract: Due to the fact that there is no A-scan display in a fully-focus phased array system, so this might cause some difficulties for the defect detection. By studying the sound field characteristics and signal characteristics of the fully-focus phased array, a new technical route of "field measurement" is proposed. The principle and the basic process of implementation were explained and the feasibility in the application of weld inspection was demonstrated. Some experiments were also given. It is pointed out that the presented field measurement technology route is beneficial to the unique characteristics of the fully-focus phased array technology and it can achieve good results.
- fully focused phased array /
- weld inspection /
- sound field characteristics /
- field measurement /
- signal to noise ratio

[1]	强天鹏,杨贵德,杜南开,等.全聚焦相控阵技术声场特性初探[J].无损检测,2020,42(1):1-6.
[2]	北京市技术交流站.超声波探伤原理及其应用[M].北京:机械工业出版社,1982.
[3]	杨贵德, 方俊钗, 詹红庆, 等. 基于相控阵全矩阵采集的全聚焦技术应用研究[J]. 无损探伤, 2016,39(2):26-27.
