铁磁性铝翅片管的近场涡流检测

详细信息

Near-field eddy current testing of the aluminum finned ferromagnetic tubes

摘要: 针对铁磁性材料铝翅片管的在役检测难的问题，使用近场涡流探头对铁磁性材料铝翅片管的在役检测开展了试验研究。结果表明：该方法可检出铁磁性材料铝翅片管的穿透性凹坑和轴向裂纹、内/外壁周向裂纹和外壁大面积壁厚损失等缺陷；对支撑结构边缘及内部的缺陷仍具有一定检出性。
- 铁磁性管 /
- 翅片管 /
- 涡流检测
Abstract: Aluminum finned ferromagnetic tubes are widely used in heat exchangers. It's in-service inspection is difficult in NDT technology. This paper shows research on near field eddy current testing technique in Aluminum finned ferromagnetic tubes inspection. The result shows that this technique has the ability to detect through hole and axial cracks, inner or outer wall circumferential cracks and large area wall thinning. The defect on edge or below the support plate can also be detected in some extent.
- ferromagnetic tube /
- finned tube /
- eddy current

[1]	任一峰.核电站汽水分离再热器用的翅片管介绍[J].发电设备,2017,31(3):185-187.
[2]	高原,张荣仁.加氢裂化在役高压空冷器翅片管束的涡流检测[J].无损检测,2010,32(4):289-292.
[3]	种玉宝, 刘明亮, 于惠君, 等. 远场涡流技术在翅片管束检测中的应用[J]. 石油化工设备, 2009, 38(2): 70-72.
[4]	范智勇, 郑超雄, 李智军, 等. 铁磁性材质铝翅片管的在役检测[J]. 无损检测, 2006, 28(5): 233-236, 241.
[5]	郭锴, 从明, 陈杰, 等. 加热炉翅片管漏磁内检测仿真分析与实验研究[J].无损探伤,2016,40(4):1-4,14.
[6]	杨理践,王赓,高松巍,等.基于脉冲远场涡流的管道内检测技术[J].仪表技术与传感器,2012(11):141-144.
[7]	黄松岭. 电磁无损检测新技术[M]. 北京: 清华大学出版社, 2014.
