Nondestructive testing of concrete steel-bar corrosion based on ERT
-
摘要: 钢筋锈蚀程度是评价混凝土耐久性和安全性的关键内容，针对实际工程中钢筋锈蚀检测方法中存在的问题，采用电阻层析成像（ERT）技术，搭建了16电极的ERT系统，采用埋入式电极注入电流采集电压的方式获取成像数据，运用基于共轭梯度法的电阻成像技术进行图像重构，完成了混凝土钢筋锈蚀无损检测的试验设计与研究。结果表明：ERT方法可以对混凝土的钢筋锈蚀状况进行可视化处理，能定性分析钢筋锈蚀的区域范围。该研究可为混凝土钢筋锈蚀无损检测提供新的思路和参考。Abstract: The durability and safety of concrete structures have always been a hot topic of research. The degree of corrosion of steel is a key part in evaluating the durability and safety of concrete. Aiming at the problems existing in the steel bar corrosion detection method in actual engineering, this paper uses electrical resistance tomography (ERT) technology to obtain imaging data by using embedded electrodes to inject current to collect voltage based on the 16-electrode ERT system. The image reconstruction was carried out by using the resistance imaging method based on the conjugate gradient method. The experimental design and research on the nondestructive testing of concrete reinforcement corrosion was completed based on the above-mentioned method. The results show that the ERT method can visualize the corrosion condition of concrete reinforcement and can qualitatively analyze the range of steel corrosion area. This study can provide new ideas and references for nondestructive testing of concrete reinforcement corrosion.
-
-
[1] 范颖芳, 胡志强, 张英姿. 受腐蚀钢筋混凝土材料力学性能研究现状[J]. 四川建筑科学研究, 2007, 33(2):59-64. [2] 贡金鑫, 赵国藩. 钢筋混凝土结构耐久性研究的进展[J]. 工业建筑, 2000,30(5): 1-5. [3] 王治民. 浅谈钢筋锈蚀对钢筋混凝土结构耐久性的影响[J]. 四川水泥, 2015(3): 277. [4] 代敏. 基于改进交流阻抗法的混凝土内钢筋腐蚀检测研究[D]. 哈尔滨: 哈尔滨工业大学, 2009. [5] TAN C H, SHEE Y G, YAP B K, et al. Fiber Bragg grating based sensing system: Early corrosion detection for structural health monitoring[J]. Sensors and Actuators A: Physical, 2016, 246(1): 123-128.
[6] ELFERGANI H A, PULLIN R, HOLFORD K M. Damage assessment of corrosion in prestressed concrete by acoustic emission[J]. Construction and Building Materials, 2013, 40(3): 925-933.
[7] 何志川. 半电池电位法检测混凝土中钢筋锈蚀的研究[D].哈尔滨: 哈尔滨工业大学, 2008. [8] DONG B, LIU Y, QIN L, et al. In-situ structural health monitoring of a reinforced concrete frame embedded with cement-based piezoelectric smart composites[J]. Research in Nondestructive Evaluation, 2016, 27(4): 216-229.
[9] 魏颖, 夏靖波, 王师, 等. 电阻层析成像(ERT)敏感场的仿真计算[J]. 东北大学学报, 2000, 21(4): 372-375. [10] 李二平, 董峰. 电阻层析成像数据采集系统的模块化设计[J]. 控制工程, 2007(Z3): 142-144. [11] 肖理庆, 王化祥. 电阻层析成像有限元模型优化[J]. 天津大学学报(自然科学与工程技术版), 2014(1): 54-60. [12] KIM B S, KIM K Y. Resistivity imaging of binary mixture using weighted Landweber method in electrical impedance tomography[J]. Flow Measurement and Instrumentation, Part A, 2017, 53(3): 39-48.
[13] 肖理庆, 王化祥, 徐晓菊. 改进牛顿–拉夫逊电阻层析成像图像重建算法[J]. 中国电机工程学报, 2012, 32(8): 91-154. [14] 蒋建华, 王强强. 基于微环境影响的混凝土电阻率计算模型[J]. 混凝土与水泥制品, 2014(12):19-22. [15] 赵恒宝. 混凝土电阻率影响因素及钢筋混凝土锈蚀损伤形态研究[D]. 大连:大连理工大学, 2008. [16] 赵磊, 张敬珍, 李康, 等. 混凝土中氯离子含量、碳化和电阻率相互关系的研究[J]. 公路交通科技(应用技术版), 2016(11):144-146.
