材料微观裂纹的光学低相干检测技术

详细信息

Optical Low Coherence Detection Technology of Material Micro Cracks

College of Automation, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China

摘要: 以材料的微观裂纹为检测对象，基于扫频光学的低相干技术原理，设计构建了马赫-泽德干涉结构的低相干系统，采用平衡探测器接收干涉光信号，并通过LabVIEW软件平台实现数据的采集与存储，得到了叶片微观裂纹的二维信息，再据此对该裂纹进行了图像重构。系统的检测分辨率可达到15.6 μm，该方法具有非侵入、检测分辨率高等优点。
- 微观裂纹检测 /
- 光学低相干 /
- 图像重构 /
- 高分辨率
Abstract: An optical low-coherence system including Mach-Zehnder interferometer is designed and applied to measure material micro cracks. Light signals are received by a balance detector, and are collected and then stored on LabVIEW platform. Images of micro cracks are reconstructed based on two-dimensional information of engine blade cracks. Its resolution is up to 15.6 μm. This method has advantages of noninvasion and high resolution.
- measurement of micro crack /
- optical low coherence /
- image reconstruction /
- high resolution

[1]	卿新林, 王奕首, 赵琳. 结构健康监测技术及其在航空航天领域中的应用[J]. 实验力学, 2012, 27(5):517-526.
[2]	VYAS N S, SIDHARTH, RAO J S. Dynamic stress analysis and a fracture mechanics approach to life prediction of turbine blades[J]. Mechanism and Machine Theory, 1997, 32(4):511-527.
[3]	孙宇博, 雷娟娟. 航空发动机叶片TC₄钛合金振动疲劳裂纹扩展研究及剩余寿命预测[J]. 表面技术, 2016, 45(9):207-213.
[4]	GARCÍA-MARTÍN J, GÓMEZ-GIL J, VÁZQUEZ-SÁNCHEZ E. Non-destructive techniques based on eddy current testing[J].Sensors,2011,11(3):2525-2565.
[5]	ERMOLOV I N. Progress in the theory of ultrasonic flaw detection:problems and prospects[J]. Russian Journal of Nondestructive Testing, 2004, 40(10):655-678.
[6]	王瑄, 李中梁, 南楠, 等. 一种提高扫频光学相干层析成像系统灵敏度的方法[J]. 中国激光, 2017, 44(8):255-261.
[7]	蔡清东, 方良, 林旺,等. 基于汉明窗算法的扫频OCT纵向分辨率的优化[J].光学仪器,2013,35(5):51-55.
