The Retained Austenite Measurement Technology by Nine-feet Sensor
-
摘要: 为了更好地研究残余奥氏体的含量同饱和磁感应强度之间的关系，在饱和磁化原理的基础上，推导出交流磁导率同金属奥氏体含量之间的关系，利用有限元法对九脚传感器的结构参数进行优化，根据优化结果制作了九脚传感器，并测量了不同奥氏体含量的Q235钢样品，结果与标定结果吻合较好，证明该方法稳定性好、精度高，适合残余奥氏体含量的测量。Abstract: Based on the saturation magnetization, the relation of the retained content of austenite and ac magnetic permeability is deduced. Optimized by finite element method, the structure of nine feet probe is used to detect some Q235 samples with different austenite content. The results are in good agreement with the samples calibration, and it tells that this method is suitable to detect the content of residual austenite.
-
Keywords:
- nine-feet probe /
- finite element method /
- magnetic permeability /
- retained austenite
-
-
[1] 肖爱武. 热处理对机床轴承用不锈钢组织和力学性能的影响[J]. 热加工工艺, 2017,46(4):200-203. [2] 钱坤, 李建鸿, 武兴斌. GCr15钢轴承残余奥氏体与疲劳寿命试验研究[J].机械制造,2009,47(6):78-80. [3] ABARESHI M, EMADODDIN E. Effect of retained austenite characteristics on fatigue behavior and tensile properties of transformation induced plasticity steel[J]. Materials & Design,2011, 32(10):5099-5105.
[4] HAMMOOD A, LIETH H M. A study the effect of retained austenite on fatigue life of austempering ductile iron by using artificial neural networks[J]. International Journal of Current Engineering and Technology, 2013, 3(5):1946-1951.
[5] 吴海燕. 残余奥氏体的摩擦诱发马氏体相变行为及其耐磨特性的研究[J]. 热加工工艺, 2007, 36(16):32-35. [6] NIKOL'SKAYA V L, PEVZNER L M, OREKHOV N G. Effect of retained austenite on the properties of cast stainless steels[J]. Metal Science & Heat Treatment, 1975, 17(9):763-767.
[7] 吴登真, 王平, 许德. 渗碳层中残余奥氏体含量的测定[J]. 汽车技术, 1988(5):27-33. [8] WIRTHL E, ANGERER R, HAUZENBERGER K.确定小型试样中残余奥氏体和铁素体数量的便利设备[J]. 钢铁, 2005, 40(6):84-86. [9] 殷春浩. 两脚磁性探头的残余奥氏体含量检测传感器:中国, CN 202974942 U[P]. 2013-06-05. [10] 李晓阳, 韩赞东, 王柄方. 基于磁性法的钢中残余奥氏体含量测定方法与装置[J]. 理化检验-物理分册, 2014, 50(12):882-885. [11] 张玉成, 鞠新华, 孟杨,等. X90管线钢中残余奥氏体含量测量的XRD与磁性法比较[J]. 钢铁, 2014, 49(11):80-84. [12] SICUPIRA F L, SANDIM M J R, SANDIM H R Z, et al. Quantification of retained austenite by X-ray diffraction and saturation magnetization in a supermartensitic stainless steel[J]. Materials Characterization, 2016, 115:90-96.
[13] 丁克勤, 王洪柱, 臧弋心, 等. 用磁各向异性传感器测定焊接残余应力[C]//第10届全国无损检测学术年会论文集.南昌:中国机械工程学会,2013.
