钢材偏析对球罐焊缝衍射时差法超声检测的影响

详细信息

The Influence of Steel Segregation on TOFD Detection of Weld of Spherical Tank

摘要: 在对球罐进行衍射时差法超声检测（TOFD）时，钢材偏析会对TOFD图谱的评定造成干扰。对1 000 m³氧气球罐球壳板进行超声波检测、TOFD检测和金相分析，再对球壳板与凸缘对接焊缝进行射线检测，从而得出检测得到的TOFD显示是由焊接缺陷产生的显示还是由钢材偏析产生的显示。
- 球罐 /
- 偏析 /
- 超声衍射时差法 /
- 超声检测 /
- 射线检测 /
- 金相分析
Abstract: When the TOFD (Time of Flight Diffraction) method is used to detect the spherical tank, the steel segregation can cause interference to the TOFD atlas assessment. In this article, UT, TOFD and metallographic analysis are used to detect welds of shell plate of 1 000 m³ oxygen spherical tank, the detection results can be used to determine whether the detected TOFD display is caused by welding defects or by steel segregation.
- spherical tank /
- segregation /
- ultrasonic time of flight diffraction technique /
- ultrasonic testing /
- radiographic testing /
- metallographic analysis
