蒸汽发生器传热管中接近管的涡流检测

详细信息

Eddy Current Testing of Proximity Tube of Heat Transferring Tubes of Steam Generator

1. Research Institute of Nuclear Power Operation Technology, Wuhan 430223, China;
2. China Nuclear Power Operation Technology Co., Ltd., Wuhan 430223, China

摘要: 针对在蒸汽发生器制造过程中，由内部倒置的相邻U形管安装误差引起的间隙距离变小而发生传热管接近的问题，在实验室条件下利用与国内某核电厂已发生接近的两根传热管的规格和工艺完全一致的试验管进行试验，得到接近管正确的涡流检测方法以及传热管接近距离和涡流幅值的关系。
- 蒸汽发生器 /
- 接近管 /
- 涡流检测
Abstract: In the manufacturing process of steam generator, the inverted adjacent U-tubes may get in very close proximity because of installation tolerance. In this paper, eddy current test of proximity extent of two adjacent tubes and relationship of proximity distance and eddy current voltage will be obtained by simulated experiment using two experimental proximity tubes having the same specification and process to those proximity tubes in one of domestic nuclear plants.
- steam generator /
- proximity tube /
- eddy current testing

[1]	李跃忠,韩良弼,王柏松.蒸汽发生器管束的固有振动分析[J].原子能科学技术,2008,42(增刊):458-462.
[2]	丁训慎.蒸汽发生器传热管的微振磨损及其防护[J].核安全,2006(3):27-32.
[3]	雷凯.蒸汽发生器传热管弯头防振条结构工艺与材料改进[J].核电工程与技术,2002,15(1):18-21.
[4]	任吉林,林俊明,徐可北.涡流检测[M].北京:机械工业出版社,2013.
[5]	孔玉莹,李金强,马强,等.蒸汽发生器传热管与防振条间隙的涡流检测[J].无损检测,2016,38(3):75-78.
