平板对接焊缝射线检测中管电压对散射比的影响

详细信息

Tube Voltage Effect on Scattering Ratio in Radiographic Testing for Plate Butt Welds

摘要: 为了了解平板对接焊缝射线检测中管电压对散射比的影响，并更好地保证底片影像质量，在其他透照参数不变的情况下，通过改变管电压来研究散射比的变化规律。结果表明：在管电流、曝光时间和焦距等参数相同的条件下，随着管电压的增加，散射比呈减小的趋势。试验为平板对接焊缝射线检测中管电压的选取提供了参考依据。
- 射线检测 /
- 平板对接焊缝 /
- 散射比 /
- 管电压
Abstract: In order to analyze the voltage effect on scattering ratio in radiographic testing for plate butt welds, so as to better guarantee the image quality of film, in this paper, the variation of scattering ratio is experimented by changing the voltage under the condition of other parameters being invariant. The results show that the scattering ratio decreases with the increase of the tube voltage when the parameters such as tube current, exposure time and focal length are fixed. The experiment provides a reference for the selection of tube voltage in the radiographic testing for plate butt welds.
- radiographic testing /
- plate butt weld /
- scattering ratio /
- tube voltage

[1]	美国无损检测学会.美国无损检测手册-射线卷[M].上海:世界图书出版公司,1992.
[2]	全国特种设备无损检测人员资格考核统编教材编审委员会.射线检测[M].北京:中国劳动社会保障出版社,2007.
[3]	彭光含,蔡新华,乔闹生,等.X射线源透射式工业计算机断层扫描成像技术在复合材料工件检测中的散射修正[J].无损检测,2007,29(4):181-184.
[4]	张小海,邬冠华,敖波.射线检测[M].南昌:机械工业出版社,2012.
[5]	于漫漫,高洪波,李泽,等. TC4和GH4169合金X射线散射比的测定及分析[J].南昌航空大学学报(自然科学版),2013,35(3):93-97.
[6]	兑卫真,杨晓华.金属材料X射线散射比的测定[J].热处理,2001(2):29-31.
