在役常压储罐管座角焊缝的相控阵超声检测

详细信息

Phased Array Ultrasonic Testing of the Socket Fillet Weld of In-service Normal Pressure Storage Tank

Petrochina Dushanzi Petrochemical Company Pressure Vessel Inspection, Karamay 833699, China

摘要: 为了提高在役常压储罐管座角焊缝缺陷的检测效率以及缺陷检测的可靠性，设计了T型角焊缝的对比试样和焊接模拟试样。采用相控阵超声检测方法成功检测出了试样中预制的5处缺陷，并与线切割结果进行了比对，检测结果与实际缺陷一致。
- 管座角焊缝 /
- 相控阵超声检测 /
- 线切割
Abstract: In order to improve the efficiency and reliability of defect detection of fillet weld for in-service normal pressure tank, samples of type T fillet weld and simulation specimen containing a total of 5 defects were designed. Experiments were performed to develop an effective method for defect detection. The prefabricated 5 defects were detected successfully, and the results were compared with the wire cutting results, showing that better detection results were obtained.
- socket fillet weld /
- phased array ultrasonic testing /
- wire cutting

[1]	彭国平,刘菊光.液化石油气储罐插入式管座角焊缝的超声检测[J].无损检测,2008,30(6):380-382.
[2]	高向明,蔡振华.浅谈特种设备管座角焊缝、角型和T型焊接接头超声检测[J].科技创新导报,2008(10):70-71.
