AP1000蒸汽发生器进出口接管超厚镍基合金预堆边焊缝的超声检测

详细信息

Ultrasonic Examination of Ultra-Thick Nickel Base Alloy Buttering Welds for AP1000 Steam Generator Inlet and Outlet Nozzle

Harbin Electric Corporation(QHD) Heavy Equipment Company Limited, Qinhuangdao 066206, China

摘要: 针对镍基合金晶粒粗大，超声波检测时声衰减严重且信噪比低，无法在完全堆焊结束后按设计图纸要求的检测方法和灵敏度进行超声波检测的问题，根据AP1000蒸汽发生器进出口接管超厚镍基合金预堆边焊缝的特点，采用特殊的超声检测工艺，制作了平行和垂直于焊接方向的两种反射体，较好地完成了超厚镍基合金预堆边的超声波检测。
- AP1000蒸汽发生器 /
- 超声检测 /
- 镍基合金预堆边
Abstract: The full thickness ultrasonic examination according to the requirement of design drawing for nickel base alloy buttering is impossible, because of coarse-grained nickel base alloy and serious attenuation and low signal to noise ratio. There exist distinctions of ultrasonic examination sensitivity in different scanning direction for anisotropic materials. According to the characteristics of the weld, specifically designed examination process of using parallel and vertical reflectors with respect to welding direction is performed to finish the ultrasonic examination of ultra-thick nickel base alloy buttering.
- AP1000 steam generator /
- ultrasonic examination /
- nickel base alloy buttering

[1]	林诚格,郁祖盛,欧阳予,等. 非能动安全先进压水堆核电技术[M].北京:原子能出版社,2010.
[2]	郑君,周凤革. 不同探头堆焊层下母材再热裂纹的比较[J].一重技术,2007(3):67-68.
[3]	郑晖,林树青.超声检测[M].北京:中国劳动社会保障出版社,2008.
[4]	聂勇,李晓梅,许远欢.核设备不锈钢堆焊层下裂纹超声波检测技术[J]. 无损检测,2011,33(7):25-28.
[5]	罗琅,王建平,奚延安,等. N08810镍基合金焊缝的超声检测[J].无损检测,2016,38(3):60-65.
[6]	王伟波,何实,杜慧燕,等. 奥氏体钢焊缝无损检测专用超声传感器的研究进展[J].焊接,2008(10):20-24.
[7]	刘凯. 正确选择和使用纵波双晶探头[J].无损探伤,2005,29(2):29-32.
