Nondestructive Testing Method of Carburized Depth Based on Barkhausen Noise
-
摘要: 提出一种基于磁巴克豪森噪声（MBN）效应的无损检测方法，用于快速地检测齿轮表面经铣削后的渗碳层深度。首先，通过对18CrNiMo7-6齿轮钢进行渗碳处理，在试样表面得到3 mm厚的渗碳层；然后在相同的进给量（0.1 mm）下依次铣削加工出有不同深度的渗碳层试样；最后，利用搭建的巴克豪森噪声检测平台对不同厚度的渗碳层进行检测。结果发现：MBN信号的均方根和均值与渗碳层深度呈近似的线性递减关系。因此，可利用巴克豪森噪声信号的均方根或均值检测铣削后的渗碳层深度。
-
关键词:
- 巴克豪森效应 /
- 渗碳层厚度 /
- 无损检测 /
- 18CrNiMo7-6钢
Abstract: A nondestructive testing method based on the effect of magnetic Barkhausen noises (MBN) is proposed to detect the carburized depth of gears which are milled. Firstly, a carburized layer of 3 mm thickness is got by carburizing treatment. Then, the samples owning different carburized depths are milled with same feed rate (0.1 mm). Finally, the Barkhausen noise detection platform was used to test the samples with different carburized depth. The results show that the relationships between the root-mean-square (RMS) value and the mean value of Barkhausen noise signal and the carburized depth are linear. It is shown that the depth of carburized layer can be tested by the root-mean-square value and the mean value of Barkhausen noise signals. -
-
[1] 孙振淋,张茜,辛玉武,等.渗碳方式对18CrNi4A钢齿轮渗碳层的影响[J]. 金属热处理, 2015,40(12):128-131. [2] 李倩,丛培武,王赫,等.18CrNiMo7-6钢齿轮真空渗碳[J].金属热处理,2017,42(3):69-71. [3] 孔德群,刘庆锁,任政,等.18CrNiMo7-6齿轮轴渗碳淬火热处理的氧化分析[J].金属热处理,2016,41(7):182-186. [4] SANTAAHOA S, VIPPOLAA M, SORSAB A. Development of Barkhausen noise calibration blocks for reliable grinding burn detection[J]. Journal of Materials Processing Technology, 2012, 212(2):408-416.
[5] STUPAKOV A, NESLUSAN M, PEREVERTOV O. Detection of a milling-induced surface damage by the magnetic Barkhausen noise[J]. Journal of Magnetism & Magnetic Materials,2016,410:198-209.
[6] 曹锐,王平,田贵云,等.齿轮材料有效硬化层深对巴克豪森噪声信号影响的研究[J].无损检测,2013,35(10):59-62. [7] 李家伟,陈积懋,穆向荣,等.无损检测手册[M]. 北京:机械工业出版社, 2002. [8] 沈功田.承压设备无损检测与评价技术发展现状[J].机械工程学报,2017,53(12):1-2. [9] TITTO S, OTALA M, SAYNAJAKANGAS S. Non-destructive magnetic measurement of steel grain size[J]. NDT International, 1976, 9(3):117-120.
[10] JAGADISH C, CLAPHAM L, ATHERTON D L. Influence of uniaxial elastic stress on power spectrum and pulse height distribution of surface Barkhausen noise in pipeline steel[J]. Magnetics IEEE Transctions, 1990, 26(3):1160-1163.
[11] LINDGREN M, LEPISTO T. Relation between residual stress and Barkhausen noise in a duplex steel[J]. NDT & E International, 2003, 36(5):279-288.
[12] VASHISTA M, PAUL S. Correlation between surface integrity of ground medium carbon steel with Barkhausen Noise parameters and magnetic hysteresis loop characteristics[J]. Materials and Design, 2009, 30(5):1595-1603.
[13] AMIRI M S, THIELEN M, RABUNG M, et al. On the role of crystal and stress anisotropy in magnetic Barkhausen noise[J]. Journal of Magnetism & Magnetic Materials, 2014, 372(12):16-22.
[14] MOSES A J, WILLIAMS P I, HOSHTANAR O A. Real time dynamic domain observation in bulk materials[J]. Journal of Magnetism & Magnetic Materials, 2006, 304(2):150-154.
