Optimization and Experimental Study of Stress Detection Parameters Based on MBN Method
-
摘要: 搭建了基于磁巴克豪森噪声（MBN）原理的电磁检测平台，以Q235钢为试验对象开展了应力检测研究。在试验之前采用不同的波形、频率和电压进行测试，分析MBN信号峰值与频率、电压的关系，确定最优的激励参数。通过静载拉伸试验确定MBN信号与拉应力之间的关系，拟合MBN信号峰值与拉应力的关系曲线，分析信号峰值作为应力评价指标的可行性。结果表明：正弦波作为激励信号产生的MBN信号特征明显、信噪比高；MBN信号峰值随拉应力的增大而先增大后减小；分析非线性拟合曲线可以对应力集中程度进行评估。Abstract: In this paper, the electromagnetic detection platform based on magnetic Barkhausen noise(MBN)principle is built, and the stress detection is carried out with Q235 steel as the experimental object. Before and after the test, different waveforms, frequencies and voltages were used to test the relationship between the peak value of MBN signal and frequency and voltage, and determine the optimal excitation parameters. The relationship between the MBN signal and the tensile stress is determined by the static load tensile test. The relationship between the peak value of the MBN signals and the tensile stress is fitted and the feasibility of using the peak value of the signal as the stress evaluation index is analyzed. The results show that the MBN signal generated by the sine wave as the excitation signal has obvious characteristics and the SNR is high; the peak value of the MBN signal increases first and then decreases with increasing tensile stress; the nonlinear fitting curve can be used to evaluate the stress concentration.
-
Keywords:
- Barkhausen noise /
- excitation parameter /
- stress detection /
- non-linear fitting
-
-
[1] SRIDHARAN U, BEDEKAR V, KOLARITS F M. A functional approach to integrating grinding temperature modeling and Barkhausen noise analysis for prediction of surface integrity in bearing steels[J]. CIRP Annals-Manufacturing Technology, 2017,66(1):333-336.
[2] DING S, TIAN G Y, DOBMANN G, et al. Analysis of domain wall dynamics based on skewness of magnetic Barkhausen noise for applied stress determination[J]. Journal of Magnetism & Magnetic Materials, 2017, 421:225-229.
[3] SORSA A, LEIVISKÄ K, SANTA-AHO S, et al. Quantitative prediction of residual stress and hardness in case-hardened steel based on the Barkhausen noise measurement[J]. Ndt & E International, 2012, 46(1):100-106.
[4] 尹何迟, 陈立功, 张光业,等. 磁巴克豪森残余应力测量技术在热处理工艺评估中的应用[J]. 热处理, 2008, 23(2):17-20. [5] 任吉林,陈曦,罗声彩,等.高周疲劳损伤的磁记忆二维检测研究[J].航空学报,2012,33(6):1147-1155. [6] MIESOWICZ K, STASZEWSKI W J, KORBIEL T. Analysis of Barkhausen noise using wavelet-based fractal signal processing for fatigue crack detection[J]. International Journal of Fatigue, 2016, 83:109-116.
[7] 林家春, 张凌浩, 石照耀. 锥齿轮齿面磨削烧伤自动检测装置设计[J]. 仪器仪表学报, 2017(5):1176-1183. [8] 王东升. 基于铁磁材料力-磁效应的磁记忆方法检测机理的基础性研究[D]. 南昌:南昌航空大学, 2006. [9] 庞娜, 程德福, 王言章,等. 时间差型磁通门敏感单元巴克豪森噪声处理研究[J]. 仪器仪表学报, 2015, 36(11):2594-2601. [10] 殷莎, 肖昌汉, 周国华. 某型船钢拉应力与磁场关系试验[J]. 海军工程大学学报, 2011, 23(3):104-107. [11] KAHROBAEE S, HEJAZI T H. A RSM-based predictive model to characterize heat treating parameters of D2 steel using combined Barkhausen noise and hysteresis loop methods[J]. Journal of Magnetism & Magnetic Materials, 2017, 433:131-140.
[12] 朱晓雪, 业成, 章彬斌. 基于巴克豪森技术的压力管道表面应力检测[J]. 中国特种设备安全, 2015(10):45-48.
