钛/钢及锆/钢复合板容器微泄漏的组合检测工艺

基金项目:

二○一五年陕西省重大科技创新专项资金资助项目（2015ZKC05-10）

详细信息

Combined Detection Technology for Micro Leakage of Titanium/Steel and Zirconium/Steel Clad Plate Vessel

摘要: 针对钛/钢、锆/钢复合板容器设备常因覆层盖板焊缝的微小缺陷造成设备在压力试验时出现微泄漏，而常规单一无损检测方法不易检出或精确定位该焊缝微小缺陷的问题，采用氦气检漏法-荧光渗透法或氨气检漏法-荧光渗透法组合的检测工艺，实现了微泄漏点的精确定位，解决了微泄漏的检测问题。
- 复合板容器 /
- 氦气检漏 /
- 氨气检漏 /
- 荧光渗透检测 /
- 精确定位
Abstract: The micro leakage often appears during pressure test of vessels equipment with titanium/steel and zirconium/steel cladding plate because of the tiny defect of the weld of the cover plate. However, the common practice single NDT method is not easy to detect or accurately position the defect. Through demonstration of three kinds of combination detection process, the results show that the helium leak detection-fluorescent penetrant method, as well as the ammonia leak detection-fluorescent penetrant method can realize accurate positioning of micro leakage point, and solve the problem of micro leakage detection.
- clad plate vessel /
- helium leak testing /
- ammonia leak testing /
- fluorescent penetrant testing /
- accurate positioning

[1]	胡学知.渗透检测[M]. 北京:中国劳动社会保障出版社,2007.
[2]	《国防科技工业无损检测人员资格鉴定与认证培训教材》编审委员会.泄漏检测[M].北京:机械工业出版社,2005.
