Application of Compton Backscattering Technique in SRM Detection
-
摘要: 介绍了康普顿背散射技术的原理、技术特点及其在固体火箭发动机检测中的应用前景。依据固体火箭发动机燃烧室结构，制备了燃烧室模拟脱粘缺陷试样。使用ComScan 160Ⅱ型康普顿背散射成像检测系统，对模拟试样进行了初步检测。结果表明：康普顿背散射成像系统能够有效检测出固体火箭发动机第一、第二界面脱粘以及绝热层内部脱粘等缺陷，对复合材料表面及近表面缺陷的单侧检测具有较大的优势，为大型工件单侧检测提供了可能。Abstract: This paper introduces the principle, technical characteristics and application prospect of Compton backscatter technology in SRM testing. According to the structure of the SRM chamber, simulated samples of debonding defect in the chamber were prepared. The ComScan 160ⅡCompton backscatter imaging system was used to test the simulated samples. The results show that the Compton backscatter imaging system can effectively test the defects in the first and second interfaces of the solid rocket motor, as well as the internal debonding in the insulation layer. Therefore, the Compton backscatter imaging system has the obvious advantage in testing the surface and near surface defects of the composite materials in one side, and opens up the possibility for testing the large products.
-
Keywords:
- compton backscatter /
- simulated sample /
- tomographic scan
-
-
[1] 刘海峰,杨兴根.背散射技术在固体发动机无损检测中的应用[J].飞航导弹, 1999(9):32-35. [2] 郑世才.康普顿散射成像技术试验[J]. 无损检测, 1995, 17(11):301-304. [3] 杨宝刚,吴东流,任华友.复合材料的康普顿背散射成像(CST)检测的初步研究[C]//第十二届全国复合材料学术会议论文集.天津:天津大学出版社,790-792. [4] BALOGUN F A, SPYROU N M. Compton scattering tomography in the study of a dense inclusion in a lighter matrix[J]. Nuclear Instruments and Methods in physics Research B, 1993, 83(4):533-538.
[5] NORTON S J. Compton scattering tomography[J]. J Applied Tomography, 1994, 76(4):2007-2015.
[6] 李家伟.无损检测手册[M].北京:机械工业出版社,2012. [7] 梁金昆.关于康普顿效应的两个问题[J]. 无损检测,1999,21(1):39-41. [8] 顾本立,葛云.康普顿背散射成像中提高散射粒子检测效率的途径[J]. 无损检测,1996,18(6):154-156. [9] 刘恩承.康普顿散射层析的一些结果和应用考虑[J]. 无损检测, 1998, 20(8):222-224.
