Application of Flash Thermal Excitation Infrared Thermographic Nondestructive Testing Equipment
-
摘要: 介绍了基于闪光灯热激励的红外热波无损检测设备，该系统采用自主研制的非制冷型热像仪，通过灯管对称排列与反光灯罩设计使得闪光灯能量的均匀性得到提高，通过红外图像降噪处理和数据重建使得红外图像信噪比得到提高。研制的热激励电源包括多种脉冲宽度控制方式，系统的控制软件可对热波图像进行采集及数字处理，增强了图像质量；操作界面采用触屏控制，使用方便。该台式系统具有高能量和完整的图像处理能力，设备便携、结构紧凑，利于在役及原位检测。Abstract: The infrared thermographic nondestructive equipment based on flash thermal excitation device was introduced. The system adopts the independent development of uncooled infrared thermal imager, the lamp symmetrical arrangement and reflective shade design makes the uniformity of the flash energy increase,the signal-to-noise ratio of infrared image is improved by infrared image denoising and data reconstruction. Independent thermal excitation power supply includes a variety of pulse width control method. The control software of the system can perform thermal wave image acquisition and digital processing to enhance image quality, and the interface adopts touch screen control,which is portable and compact.The system facilitates the detection of in-service and in-situ.
-
Keywords:
- flash thermal excitation /
- pulse heat excitation /
- thermographic
-
-
[1] 王迅,金万平,张存林,等.红外热波无损检测技术及其进展[J].无损检测,2004,26(10):497-501. [2] 刘颖韬,郭广平,杨党纲.脉冲相位法用于复合材料层析检测的研究[J].激光与红外,2009,39(14):390-392. [3] 郭兴旺,许文浩.蜂窝结构积水的脉冲红外热像无损检测的传热分析[J].红外技术,2011, 33(5):275-280. [4] 张雨, 王玉国, 龚俊杰.列车门覆板-铝蜂窝脱粘缺陷的红外热像检测[J].激光与红外,2013,43(2):176-179. [5] 李晓丽,曾智,张存林,等.红外热波无损检测技术用于风电叶片粘接质量的检测[C]//无损检测高等教育发展论坛暨电磁超声无损检测技术交流会.[S.l.]:[s.n],2011. [6] 刘颖韬,郭广平,温磊,等.红外热像检测技术应用于蜂窝结构复合材料的检测能力评价[J].无损检测,2011,33(12):81-84. [7] 张南南,郭兴旺.固体火箭发动机绝热层脱粘的红外无损检测建模方法[J].无损检测,2016,38(8):1-5. [8] SHEPARD S M. Advances in pulsed thermography[C]//Proceedings of SPIE.[S.l.]:[s.n],2001.
[9] 江海军,陈力,张淑仪.激光扫描红外热波成像技术在无损检测中的应用[J].无损检测,2014,36(12):20-22.
