基于FPGA+ARM的管道漏磁检测数据采集系统设计

基金项目:

国家重大科学仪器设备开发专项基金资助项目（2012YQ090175）

详细信息

Design of Pipeline MFL Detection Data Acquisition System Based on FPGA and ARM

Pressure Pipeline Division, China Special Equipment Inspection and Research Institute, Beijing 100029, China

摘要: 提出了一种基于FPGA与ARM架构的管道漏磁检测数据采集方案，给出了系统的硬件设计方案，包括AD转换模块与FPGA连接设计，FPGA与ARM之间的接口设计；并给出了数据采集系统软件设计，包括数据采集系统程序设计和上位机调试软件设计。系统测试结果表明，系统集成度高、应用灵活；设计具有精度高、动态范围大的特点，是一种实现漏磁检测数据高精度采集处理的高效可行的解决方案。
- 管道漏磁检测 /
- 数据采集系统 /
- FPGA /
- ARM /
- AD转换模块
Abstract: MFL detection data acquisition scheme based on ARM and FPGA architecture is proposed, and the system hardware design project is provided. The overall design of the system has been given, including the AD conversion module, the design of FPGA connection, and the communication design between ARM and FPGA. The software design of data acquisition system is also given, including data acquisition system program design and host computer debugging software design. The system is highly integrated and of flexible application. System test results show that the design has the characteristics of high precision and large dynamic range, it is an efficient and feasible solution to realize high precision acquisition and processing of magnetic flux leakage testing data.
- pipeline MFL testing /
- data acquisition system /
- FPGA /
- ARM /
- AD converter

[1]	刘群,黄松岭,赵伟,等.海底管道缺陷漏磁检测器数据采集系统研发[J].中国测试,2015,41(1):89-92.
[2]	单少卿,陈世利,靳世久,等.高清晰度三轴管道内检测器漏磁数据采集系统[J].传感器与微系统,2012,31(5):118-121.
[3]	张宝利,龚龙庆,方超,等.基于ARM+FPGA的重构控制器设计[J].现代电子技术,2010,312(1):195-197.
[4]	尹勇生,杨鑫波,邓红辉,等.应用于高速高精度流水线ADC中的差分参考源[J].现代电子技术,2012,26(2):1043-1049.
[5]	李宁.ARM Cortex-A8处理器原理及应用[M].北京:北京航空航天大学出版社, 2012.
[6]	王坤,黄松岭,赵伟,等.高清晰度油气管道腐蚀检测器数据分析系统设计[J].天然气工业,2007,27(1):108-110.
[7]	胡西洋,沈功田,卢超,等.漏磁检测仪检测通道一致性评价试验[J].无损检测,2015,37(9):26-29.
[8]	朱红秀,杨博玺,黄松岭.管道漏磁检测系统中数据显示方法[J].无损检测. 2013,35(9):5-9.
