The Detection of Internal Defects of Concrete Based on the Imaginary Part of the Frequency Response Function and Singular Value Entropy
-
摘要: 根据相干函数和力锤激励的有效频段来确定频响函数的研究频段，再将频响函数虚部与信息熵理论相结合，计算频响函数虚部构造的Hankel矩阵的奇异值熵，最后通过概率法计算出异常情况的判断值来实现对混凝土内部缺陷的检测。在此基础上提出了一种简单实用的混凝土缺陷成像的定性分析方法，首先利用各扫射射线的奇异谱熵值将试件分为最有可能产生缺陷与最不可能产生缺陷的区域，再计算各缺陷单元格的投影函数值，非缺陷单元格的投影函数值置0，最后用各单元格的投影函数值的等高线来反应混凝土内部情况，并通过试验验证了该方法的有效性。Abstract: Based on the coherence function and effective frequency band of hammer excitation,the frequency band of the frequency response function was determined. Then the imaginary part of frequency-response function and the information entropy theory were combined to calculate the singular value entropy of Hankel-matrix which was constructured by the imaginary part of the frequency-response function. Finally, probabilistic method was used to calculate the abnormal condition and examine the internal defects of concrete. Based on these, the paper offers a simple and practical method of qualitative analysis to image the concrete defect. Firstly, the specimen was divided into two zones to differ in degree of defect.Then the projection function value of the defect cell was calculated and the non-defect cell was set to zero.Lastly, the inside situation of concrete was reacted by the contour of the projection function,and the test was performed to assess availability of the method.
-
Keywords:
- Singular value entropy /
- Frequency response function /
- Coherence function /
- Defect
-
-
[1] E P, FANNING P. Vibration based condition monitoring:a review[J].Structural Monitoring,2004,3(4):355-377.
[2] 杨彦芳,宋玉普. 基于主元分析和频响函数的网架结构损伤识别方法[J]. 工程力学,2007,24(9):105-110. [3] 高海洋,郭杏林,吴明勇.基于频响函数虚部的板结构损伤检测方法研究[J].振动与冲击,2012,31(12):86-91. [4] 方剑青,矫桂琼. 基于频响函数的结构状态识别神经网络方法[J]. 振动、测试与诊断, 2007,27(1):45-47. [5] WANG Z,LIN R M,LIM M K. Structural damage detection using measured FRF data[J]. Computer Methods in Applied Mechanics and Engineering,1997,147:187-197.
[6] YAM L H,LEUNG T P,LI D B, et al. Use of ambient response measurements to determine dynamic characteristics of slender structures[J]. Engineering Structures,1996,18(3):145-150.
[7] 李睿,于德介,曾威. 一种基于奇异谱熵和脉冲响应的结构损伤诊断方法[J]. 振动工程学报,2006,19(3):331-335. [8] 谢中凯,刘国华. 近似熵在混凝土结构损伤识别中的应用[J]. 浙江大学学报(工学版),2013,47(3):456-463. [9] 刘国华,谢中凯. 一种用于检测梁结构损伤的改进传递熵[J]. 振动工程学报,2014,27(1):136-144. [10] 钱济国. 频响函数测量的脉冲激励法[J]. 振动、测试与诊断,1994,14(2):32-39. [11] 吴佳晔. 土木工程检测与测试[M]. 北京:高等教育出版社,2015. [12] 罗骐先.桩基工程检测手册[M].北京:人民交通出版社,2003:181-258. [13] 吴慧敏.结构混凝土现场检测新技术——混凝土非破损检测[M].长沙:湖南大学出版社,1998:161-164.
