The Phased Array Ultrasonic Testing of Butt Fusion Joint in Polyethylene Pipe
-
摘要: 在研究聚乙烯管道热熔对接接头超声检测中超声波反射规律的基础上，提出对该接头使用超声相控阵检测技术。研制了基于相控阵聚焦和超声实时成像技术的超声自动检测系统，通过液体楔块的声阻抗匹配，克服了聚乙烯材料声衰减严重和检测界面声能损耗对超声检测造成困难的问题。通过制作典型缺陷的聚乙烯接头缺陷试样，进行了可靠性测试和工艺试验，结果表明，提出的超声相控阵检测技术能可靠地检测出聚乙烯热熔对接接头中的典型缺陷。Abstract: Polyethylene (PE) pipe has been widely used for the transportation of gas in cities because of its excellent corrosion resistance, good mechanical properties and longer service life. Fusion welding is one of the main connection methods of polyethylene pipe. On the basis of the research on the ultrasonic reflection of different type defects in the joint,the phased array ultrasonic technique is presented. An automatic ultrasonic testing system is designed and fabricated with phased array electronic focusing technique and real-time imaging technique,which is comprehensively to integrate impedance matching with acoustic coupling technique, with the purpose of overcoming the detecting difficulty caused by the attenuation of PE and transmitting loss at interface.The reliability and process performance are tested through detecting PE joints with typical defects. It is shown that the phased array ultrasonic technique presented in the paper is applicable for detecting typical defects in of butt fusion joint in Polyethylene Pipe.
-
-
[1] 北京市燃气集团公司技术培训中心.聚乙烯燃气管道施工技术教程[M].北京:中国劳动社会保障出版社,2002. [2] 秦永泉. 含工艺缺陷聚乙烯管道热熔焊接接头力学性能试验研究[D]. 杭州:浙江大学,2010. [3] 李克明,刘德荣,张志永,等.超声波探伤[M].北京:水利电力出版社,1985. [4] 日本非破坏检查协会.超声波检测[M].马羽宽,译.长春:吉林科学技术出版社,1985. [5] 郑晖,林树青.超声检测[M]. 北京:新华出版社,2008. [6] 施克仁,郭寓岷.相控阵超声成像检测[M].北京:高等教育出版社,2010. [7] 潘亮,董世运,徐滨士,等.相控阵超声检测技术研究与应用概况[J]. 无损检测,2013,35(5):25-29. [8] 郭伟灿,殳宏,朱联华.聚乙烯管道热熔接头耦合聚焦检测技术的试验研究[J].无损检测,2014,36(6):43-47. [9] 王军.超声相控线阵换能器的凡何优化设计[D]. 上海:机械科学研究院,2002. [10] 涂春磊,邹建华,强天鹏,等.对接焊缝相控阵超声检测可靠性的CIVA仿真与试验[J]. 无损检测,2013,35(11):22-26.
